Help CenterCE Approved 3030 18W LED Modern Kitchen Lamps
Related Products
-
High Power 27W 600x600 Led Light LampUS$ 45 - 80MOQ: 1 Piece -
Super Daylight Led Panel Light 30120 Panel Light 36wUS$ 50 - 90MOQ: 1 Piece
-
54W 600x600mm 6 Inch Led Panel Light From Chinese Professional ManufactureUS$ 55 - 95MOQ: 1 Piece
-
300*1200 Virtual Led Panel tv 36WUS$ 40 - 80MOQ: 1 Piece
-
Popular Rgb Led Panel Light Dmx 600*600 42W Led LightUS$ 70 - 110MOQ: 1 Piece
Specifications
1.CE approved 3030LED panel2.Uniformed luminance
3.High light transmission rate
4.100% aluminum frame
5.Taiwan LumenMax LED
CE Approved 3030 18W LED modern kitchen lamps
Product description :
300x300x12mm LED Panel Lights
(1) South Korea's Samsung SMD5630 LEDs, Taiwan LumenMax SMD5630 or SMD3014 LEDs are available.
(2) MEAN WELL Power Supply or Bipolar Drive Power Supply are available.
(3) With high light transmission rate , excellent light uniformity, and effectively prevent static electricity and dust.
(4) Professional aluminum structure design and PCB circuit design to ensure the SMD LEDs good for heat dissipation.
(5) Alternative Power :18watt/24watt/27watt / 36watt (6) Standard CE RoHS ETL UL FCC TUV.
(7) One remote can control many pieces of Panel Light and the panel lights can be divided into four groups and control separately
Technical specifications:
| Model No.: | LVT-PL3030*18W* |
| Size: | 295x295x12mm (300x300x12mm) |
| Power: | 18W |
| 1170lm ( 18W ) | |
| Input Voltage: | AC 100-277V (UL certification) AC100-240V (CE certification) |
| LED Brand Chips: | Option-1: Taiwan LumenMax SMD3014 LEDs (10*23MIL) |
| Option-2: Taiwan LumenMax SMD5630 LEDs (42*25MIL) | |
| Option-3: Korea Samsung SMD5630 LEDs (42*25MIL) | |
| are available | |
| Dimmable: | Dimmable or Non-Dimmable |
| Color Temperature: | 2800~6500K |
| CRI: | >80 ( SMD5630 LEDs ) |
| >72 ( SMD3014 LEDs ) | |
| Net Weight: | 1.35Kg |
| Gross Weight: | 1.65Kg |
| Installation Methods: | Recessed / Suspended / Wall Mounted / Ceiling Mounted |
| Warranty: | 3 years |
Advantages:
- Super slim design, save 70% energy, High efficiency 70LM/W with uniformed luminance.
- Life span: 50000 hours
- Wide range of input voltage: AC100-270V
- Instant start, no noise, no flickering
- New high efficiency constant current driver.
- Professional circuit design, each group of LEDs work separately to avoid any problem of lighting output caused by single faulty LED.
- No electrical wave interference, confirm to the standard of CE.
- No plumbum, green environment friendly, confirm to the standard of RoHS.
- No RF interference.
About US:
SHENZHEN LOEVET LIGHTING CO.,LTD.
Shenzhen Loevet Lighting Co.,LTD is an experienced manufacturer of LED lighting fixture in China ,devotes to R&D,Production and sale.Specializing in all kinds of LED lighting by Light-emitting panel: Square LED Panel Light,Round LED Panel Light,Rectangular LED Panel Light Circular LED Down light,LED Ultra-Thin Ceiling Panel Light..ect.
All of our products are widely used for commercial lighting and decoration,home and residence lighting,hotel and exhibition lighting and decoration:Hotel Meeting Room,Factory & Office,Commercial Purpose,Residential & Institution,School,Hospital and other lighting location.Our products have got CE,ROHS,UL ,FCC,SAA approved and many other international certifications.
"Technology, quality, service" is our three core competitiveness,leading the company to toward the industry’s most high-end fields.
Factory show :
Our R&D team have Eight professional technical elite,the cores are as follows: Engineer Chen:LED panel lamp structure engineer,over 7 years experience Engineer Cen:LED panel lamp electronic engineer,over 7 years experience Engineer Li:LED panel lamp power engineer,over 10 years experience.
Application Scope :
Hotel Meeting Room Factory & Office
Commercial Purpose Residential & Institution School
Hospital Other lighting location
Certificates :
Package :
Inner Box: 385×385×55mm (1pcs/box) Net Weight: 1.35KG Gross Weight: 1.65 KG
Outer Carton: 400×400×240mm (4pcs/carton) Net Weight: 6.6 KG Gross Weight: 7.35 KG
4 boxes packed in a Carton
About installation:
1. Panel lights should be installed by trained electronic technician.
2. Please check all the accessories when open the cartons.
3. The distance between the light and any flammable materials must be more than 0.2m. The distance between the upper part of the installed light and the ceiling must not be less than 2 cm. Don not install into ceilings or walls that contain heat source. The main cable must not connect with the low voltage cable or the surface-mounted lights.
4. Guide the lights' connecting cables through the drilled hole, and fix the surface-mounted lights with the pre-fitted clips. Make sure that these are securely connected to the base material.
5. When laying the cables, make sure that the cables and plugs are not subjected to any tensile or twisting forces. Do not kink cables. Output cables should be laid separately and at a distance from other cables.
6. After installation, connect the transformer to the mains supply
7. Proceed by connecting the wiring cables to the lights. Usually, the brown (or black) wire is the Live wire, connect it with the terminal marked "L". The blue wire is Naughty wire; connect it with the terminal marked "N".
8. Use the dedicated LED drivers only, do not connect to other loads
9. Do not remove the label of the lights and drivers.
Remarks for LED panel lights:
*Avoid minefields, strong magnetic field and high pressure field when installing the panel lights.
*Ensure that the connection is secure and correct,to avoid short circuit in order not to damage components thus result in a fire.
*Before using the panel light, please check if the local voltage is suitable for the panel lights.
*Before connecting the panel lights to the power,check if the connection is correct or not,confirm there is no short circuit,and then it can be used.
