Help CenterTM-8812C Ultrasonic Wall Thickness Meter
Related Products
-
TM-8812 Ultrasonic Wall Thickness GaugeUS$ 119.5 - 125MOQ: 1 Piece -
TM-8816 Ultrasonic Pipe Thickness MeterUS$ 119.5 - 125MOQ: 1 Piece
-
TM-8818 Ultrasonic Pipe Thickness Gauge 0.9~400mmUS$ 268 - 280MOQ: 1 Piece
-
CM8811FN Build-in Probe Paint Coating Thickness GaugeUS$ 135 - 160MOQ: 1 Piece
-
CM8801FN Digital Coating Thickness GaugeUS$ 89.79 - 105MOQ: 1 Piece
chemical equipment ultrasonic thickness measuring instruments with 0.01 mm Resolution
Applications:
Used for measuring thickness and corrosion of pressure vessels,chemical equipment, boilers,oil storage tanks,etc.in industries
of petroleum, shipbuilding,power station,and machine manufacturing.
Features:
* Using the latest high performance and low power consumption microprocessor technology.
* Automatic memory material code and sound velocity value, convenient to use.
* Use “USB data output” and “RS-232 data output” to connect with PC. (NOTES: RS232/ USB cable+software is optional part)
* Provide “Bluetooth™ data output” choice.(NOTES: Bluetooth data output with software is optional part)
Details:
Display: 4 Digit, 10 mm LCD
Operating Principle: Ultrasonic
Measuring Range (metric / Imperial) : 1.0~200 mm / 0.04~8 inch
Battery Indication: Low Battery Indication
Sound Velocity: 1000~9000 m/s
Lower Limit Steel Pipes: Diameter:15 x 2.0 mm/ Diameter: 20 x 3.0 mm determined by transducer
Calibration Block: Included
Resolution: 0.01 mm
Accuracy: ± (0.5%n + 0.1)
Automatic memory material code and the value of sound velocity
Power off: Auto Power off & Manual Power Off
Operating Conditions: Temperature: 0~40 °C, Humidity: < 85 %RH
Power Supply: 4 x 1.5 V AAA (UM-4) Battery
Dimensions: 120 x 62 x 30 mm
Weight: 164 g (Not Including Batteries)
Standard Accessories:
1. Main Unit
2. 5M Diameter 8 Standard Sensor
3. Coupling Agent
4. Carrying Case
5. Operating Manual
Optional Accessories:
1. 6M Diameter 6 mm thin Material Probe : Measuring range (steel): 1.0~50.0 mm
Operating temperature: -10~60°C
2. 5M Diameter 12 mm High Temperature Probe: Measuring range (steel): 1.0~225.0 mm (normal temperature)
Measuring range (steel) : 4.0~100.0 mm (high temperature)
Operating temperature: -10~300°C
3. Curved Surface Probe
4. USB, RS-232C data cable with software
5. Bluetooth data output with software
Starmeter Instruments Company.,LTD ,located in Shenzhen Guangdong, was established in 2002. Our company is a hightech enterprises based on research and development, manufacture and distribution of instruments and meters, specialized in promotion and distribution of the home made instruments in the international market.
Our main products lines are non-destructive testing and environment measurement products, covers Coating Thickness Gauge, Laser Distance Meter ,Infrared Thermometer,Anemometer, Tachometer , Sound Level Meter , Lux meter ,Humidity Meter and so on.All of our products have CE, ROHS certification, 80% of the products were sold to more than 30 Western countries and another 20% to Asian countries and home.Our "NICETY" brand has taken credit for high accuracy,good durability and elegant design for years...
Why would you choose us?
We offer factory price products
We accept small quantity & wholesale orders (NO MOQ)
We keep our stocks available for anytime order
We offer the lowest shipping cost via DHL, FedEx or UPS
Super customer support: post sale support that responds within 24 hours
Wide range of innovative products
