Help CenterLantian Brand Machine Of Retail Duck Feed Pellet Mills
Related Products
-
Market Wholesale Poultry Pellet Feed MachineUS$ 500 - 5,000MOQ: 1 Set -
Factory Wholesale Poultry Feed Pellet MakerUS$ 500 - 5,000MOQ: 1 Set
-
Factory Wholesale Machine To Make The Pellet In HomeUS$ 500 - 5,000MOQ: 1 Set
-
Speak Highly Of Floating Fish Feed Pellet MachineUS$ 500 - 40,000MOQ: 1 Set
-
Professional Manufacturer of Machine For Make Pellet WoodUS$ 500 - 40,000MOQ: 1 Set
♥ Introduction of duck feed pellet mills:
1. Duck feed pellet mills is mainly used to make the biofuel pellets or animal pellets from wood, straw, cotton stalk, rice husk, peanut shell, bamboo, empty fruit branch, pulverized coal and waste paper, etc.
2. The final pellets are of high density, high fuel value, low moisture and low ash content.
3. Duck feed pellet mills is energy saving machine which can recycle and reuse the agriculture wastes to protect environment.
4. The outlet pellets can be 4-30mm size for option and the pellets can be used for fireplace, animal feed, burning for stove, etc.
5. The duck feed pellet mill can be used in electric industry, fertilizer industry, animal feed industry, etc.
♥ Duck feed pellet mills are optional:
1. Small duck feed pellet mills:
1). Structure: This series of duck feed pellet mills are consist of Electric motor/Diesel Engine, Gear Box, Axis, Flat Die, Roller, Feeding room, Cutting blade, Outlet.
2). Working principle: This series duck feed pellet mills uses the diesel engine or electric motor as power. The gears derive the spindle and die. The raw materials are forced out of the die holes by the squeezing action of the die and roller. Then the high quality pellets are produced. The length of the pellets can be controlled by adjusting the position of the tool bit.
Model |
Power |
Capacity for fuel pellet |
Capacity for animal feeds |
Moisture |
Dimension (CM) |
Gross Weight (KG) |
LTSP-120A |
8HP Diesel engine |
40-60 KG/H |
40-60 KG/H |
12%-20% |
90*44*73 |
135 |
LTSP-120B |
3KW 380V 50HZ |
50-100 KG/H |
100-200 KG/H |
12%-20% |
75*31*62 |
100 |
LTSP-150A |
8HP Diesel engine |
50-100 KG/H |
100-200 KG/H |
10%-15% |
87*46*73 |
150 |
LTSP-150B |
4KW 380V 50HZ |
90-120 KG/H |
150-220 KG/H |
10%-15% |
77*34*68 |
115 |
LTSP-150C |
4KW 380V 50HZ |
90-120 KG/H |
90-120 KG/H |
10%-15% |
77*34*68 |
115 |
LTSP-200A |
15HP Diesel engine |
110-180 KG/H |
220-350 KG/H |
10%-15% |
118*56*102 |
360 |
LTSP-200B |
7.5KW 380V 50HZ |
100-150 KG/H |
200-300 KG/H |
10%-15% |
100*43*95 |
210 |
LTSP-200C |
7.5KW 380V 50HZ |
200-300 KG/H |
200-300 KG/H |
10%-15% |
100*45*93 |
220 |
LTSP-200D |
7.5KW 380V 50Hz |
200-300 KG/H |
200-400 KG/H |
10%-15% |
110*76*95 |
400 |
LTSP-230A |
22HP |
150-200 KG/H |
300-400 KG/H |
10%-15% |
118*56*95 |
390 |
LTSP-230B |
380V 50HZ 11KW |
150-200 KG/H |
300-400 KG/H |
10%-15% |
114*50*97 |
310 |
LTSP-230C |
11KW 380V 50HZ |
150-200 KG/H |
300-400 KG/H |
10%-15% |
115*50*97 |
320 |
LTSP-260A |
30HP |
200-300 KG/H |
400-600 KG/H |
10%-15% |
184*70*116 |
630 |
LTSP-260B |
15KW 380V 50HZ |
200-300 KG/H |
400-600 KG/H |
10%-15% |
120*50*103 |
360 |
LTSP-260C |
15KW 380V 50HZ |
200-300 KG/H |
400-600 KG/H |
10%-15% |
120*50*103 |
370 |
LTSP-300A |
55HP |
300-400 KG/H |
600-800 KG/H |
10%-15% |
220*60*123 |
780 |
LTSP-300B |
22KW 380V 50HZ |
300-400 KG/H |
600-800 KG/H |
10%-15% |
132*53*107 |
470 |
LTSP-300C |
22KW 380V 50HZ |
300-400 KG/H |
600-800 KG/H |
10%-15% |
132*53*107 |
480 |
Series A:
Series B:
Series C:
2. Rotating Rollers feed pellet mills:
1). Structure: This kind of duck feed pellet mills is consist of PTO shaft, Gear Box, Axis, Flat Die, Roller, Feeding room, Cutting blade, Outlet.
2). Working principle: The biomass material has been on the die through the feed hopper. The press roller has been driven by principle axis, then press roller has extend the material to the nib, the material has been shaped to the cylindrical pellet in the nib for certain time and would be cut the rotary slicer, then moved to the discharge hole.
| Model | Power | Capacity | Net/Gross Weight | Dimension |
| LTMP-200B | 7.5 kw | 80-120 kg/h | 350/370 kg | 1.15x0.53x1.0 m |
| LTMP-300B | 22 kw | 200-350 kg/h | 575/595 kg | 1.3x0.6x1.15 m |
| LTMP-400B | 30 kw | 300-450 kg/h | 810/830 kg | 1.4x0.7x1.6 m |
LTMP-400B:
3. Verticle Flat Die duck feed pellet mill:
1). Simple structure, easy operation, stable working and can continuously working.
2). The outlet pellets from these machines are of high density, high combustion value, low moisture, low ash, etc.
3). The gearbox adopt high precision gear transmission and four groups of gears docking.
4). Automatic lubrication system for bearings and rollers. When the machine's working, the oil pump is working too. On the condition of automatic lubrication system, the using life of main shaft and bearings will be greatly increased.
5). The mold and rollers are made from hard material of alloy steel. Through thermal treatment, their hardness can be up to 50, which greatly increase the life of the wood pellet machine.
Model |
Power |
Capacity |
Dimension (CM) |
Weight (KG) |
LTP-350 |
30KW |
300-500 KG/H |
165*70*130 |
1000 |
LTP-450 |
37KW |
500-700 KG/H |
130*70*150 |
1450 |
LTP-550 |
45KW |
800-1000 KG/H |
140*75*160 |
2000 |
LTP-800 |
90KW |
1500-2000 KG/H |
190*100*200 |
3900 |
LTP-1000 |
110KW |
2000-3000 KG/H |
210*115*205 |
4800 |
LTP-450:
LTP-350:
♥ Packaging and Shipping:
♥ Related Pellet Production Line:
Generally, the machine for pellet production line includes croase crusher, fineness crusher, dryer, feeding machine, pellet machine, coolling device, separating device, lifting device and conveyor.
♥ Our services:
1. Pre-sales service:
1). sales person, project manager, technology engineer, accountant staff.
2). pofessional responding team: would be very fastly and exactly to send you offer.
3). choose suitable machines and make producing plan according to the raw materials, final shapes and output capacity.
4). offer reasonbal price to meet your budget.
5). invite customers to our factory, demostrate the machines, let you know how the machine work, and compare the quality with other suppliers.
6). producing super and solid quality of machines.
7). arrange shipping and fastly delivery.
8). standard export package or as your requirements.
2. After-sales service:
1). assistance to build factory.
2). repairing and maintain if any problems occur in the warranty.
3). help for installation or clerk training, if necessary, dispatch technicians to your country to install the machines.
4). supply spare and wearing parts of our machines.
5). any feedback of our machine for make pellet wood can be told us, and we will try our best to support you.
6). technology knowlogy shares with you.
7). help for any other machine that we haven't.
♥ Contact information:
If there is any interest in our machine, please don't hesitate to contact me.
