C Band Quad Lnb Factory Price

C Band Quad Lnb Factory Price thumbnail-1
C Band Quad Lnb Factory Price photo-1
US$ 4.98 - 6.49 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
risesat
Model Number:
RS-C1024
Contact Supplier Request Quote Chat Now
Anhui Risesat Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Anhui, China
Brand Name risesat
Model Number RS-C1024

Specifications

C band quad lnb
1.Dual Polarity Switchable
2.Super low Noise&Digital Ready
3.High Gain Output
4.17"K

ANHUI RISESAT ELECTRONI CO.,LTD

C band quad lnb factory price









Product Description

  C band quad  lnb





C BAND quad  LNB

1.Input Frequency Range 3.4~4.2GHz
2.Output Frequency Range 950~1750MHz
3.L.O. Frequency Range 5.15GHz
4.F/D Ratio 0.28~0.42(Adjustable)
5.Input Reflector Type Prime focus
6.Cross Pol. Isolation 20 dB(Typ.)
7.Noise temperature 15 oK
8.Conversion Gain 65dB(Typ.)
9.Gain Flatness +1 dB/36 MHz
10.L.O. Frequency Stability +1.0 MHz @25°C           +2.5 MHz @(-30°C~+60°C)
11.L.O. Phase Noise (1 KHz Offset)                                            -70 dBc/Hz @10 KHz
                    (10 KHz Offset) -85 dBc/Hz @100 KHz
                    (100 KHz Offset) -105 dBc/Hz @1 MHz
12.Image Rejection 45 dB (Min.)
13.Output power 0 dB (Min.)
(at 1 dB Gain compression Point)
14.Output Return Loss 7.5 dB
15.Output Connector 75 ohm F type (female)
16.D.C. Supply Voltage 12~24VDC
17.D.C. Current Consumption 150 mA (max.)
18.Polarity Switching Voltage Vertical: 11.5~14.5 VDC  Horizontal:15.8~19 VDC
19.Operating Temperature -40°C~+60°C







C band quad lnb factory price





C band quad lnb factory priceC band quad lnb factory priceC band quad lnb factory price
