JAC CPCD50 Hydraulic Drive JAC Forklift

JAC CPCD50 Hydraulic Drive JAC Forklift thumbnail-1
JAC CPCD50 Hydraulic Drive JAC Forklift photo-1
US$ 1 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
China
Brand Name:
JAC
Contact Supplier Request Quote Chat Now
Kunshan Hanzhi Logistics Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin China
Brand Name JAC
Model Number CPCD30
After-sales Service Provided Engineers available to service machinery overseas

Specifications

We are Jac Forklift Agency, JAC forklift is famous with good quality and stable work ability.



Model CPCD50-W2

Load Capacity 5000

Tire Type Pneumatic

Model ISUZU 6BG1 DIESEL ENGINE

Rate Horsepower kw/r. P. M 82(112)/2000

Rate torque N. M (kg. M) r. P. M 415/1400-1600

Number of Cylinder 6

Fuel Tank Capacity 6.494

Displacement 140

Model CPCD50
Overall height fork raised mm 4420 Wheel base mm 2250
Max lifting height mm 3000 Rear overhang mm 600
Overall height fork mm 2500 Overall height mm 2450
Backrest height mm 1365 Overall width mm 1995
Free lift mm 190 Later fork adjustment mm 300-1835
Fork thickness mm 60 Tread front mm 1470
Min under-clearance mm 200 Tread rear mm 1700
Overall length(with forks) mm 4660 Fork width mm 150
Overall length(without forks ) mm 3440 Outside turning radius mm 3300
Fork length mm 1220 Min intersecting aisle mm 2960
Front overhang mm 590 Tilting angles (forward/backward)   6°/12°





JAC CPCD50 Hydraulic Drive JAC ForkliftJAC CPCD50 Hydraulic Drive JAC ForkliftJAC CPCD50 Hydraulic Drive JAC ForkliftJAC CPCD50 Hydraulic Drive JAC Forklift



JAC CPCD50 Hydraulic Drive JAC Forklift

Technical Parameters



Model

CPC
15FR

CPCD
15FR

CPC
18FR

CPCD
18FR

CPC
20FR

CPCD
20FR

CPC
25FR

CPCD
25FR

CPC
30FR

CPCD
30FR

CPC
35FR

CPCD
35FR

CPC
40FR

CPCD
40FR

Load capacity kg

1500kg

1800kg

2000kg

2500kg

3000kg

3500kg

4000kg

Load center mm

500mm

Power type

Diesel

Max.lifting speeds
(with load)mm/s

500mm/s

400mm/s

375mm/s

300mm/s

Max.Driving speeds
(with without load)km/h

14.5/15km/h

17/19km/h

18/20km/h

17/19km/h

18/20km/h

Max.Towing speeds
(with/without load)kN

14.4/8.4kN

14.4/9.1kN

14/9kN

15/10kN

15.5/10.5kN

16/11kN

16.5/11.5kN

Gradeability
(with/without load)%

15/20%

H1 Lifting height mm

3000mm

Free lift mm

70mm

60mm

80mm

Tilting angles(forward-backward) .

6/12 .

Min. turning radius mm

2000mm

2450mm

2500mm

2720mm

Min. right angle aisle width mm

1770mm

2050mm

2110mm

2320mm

Min. under-clearance mm

110mm

135mm
