Help CenterQAY400
Related Products
Specifications
Adopt the closed hydraulic system, power management function of the multi-pump system, featuring more stable operation and goodDimension |
Unit |
QAY400 |
Overall length |
mm |
18850 |
Overall width |
mm |
|
Overall height |
mm |
4000 |
Weight | ||
Overall weight in transport |
kg |
84000 |
Front axle load |
kg |
|
Rear axle load |
kg |
|
Power | ||
Engine model |
TAD750VE |
|
Engine rated power |
kW/(r/min) |
200/2300 |
Engine rated torque |
N.m/(r/min) |
2700/1080 |
Travel | ||
Max. travel speed |
km/h |
70 |
Min. turning diameter |
m |
25 |
Min. ground clearance |
mm |
|
Approach angle |
° |
16 |
Departure angle |
° |
14 |
Max. grade ability |
% |
40 |
Fuel consumption for 100km |
L |
|
Main performance | ||
Max. rated total lifting capacity |
t |
400 |
Min. rated working radius |
mm |
|
Turning radius at turntable tail |
m |
|
Max. lifting torque |
kN.m |
12152 |
Base boom |
m |
|
Fully extended boom |
m |
|
Fully extended boom+ jib |
m |
|
Longitudinal outrigger span |
m |
9.5 |
Lateral outrigger span |
m |
9.8 |
Working speed | ||
Boom luffing time |
s |
|
Boom full extension time |
s |
|
Max. swing speed |
r/min |
|
Max. speed of main winch (single rope) (no load) |
m/min |
|
Max. speed of aux. winch (single rope) (no load) |
m/min |
|
