Mimaki digital sublimation printer
This Mimaki direct textile printing solution can make the Mimaki printer to be used in Direct Textile Printing. Other Mimaki series printer can also be customized on this Digital Textile Printing Machine.
1. Wider application field.
This solution can convert the Mimaki printer to print images on Fabric directly. This optimization do improved the application field of this Large Format Printer in Digital Textile Printing, Fabric Textile Printing, Heat Transfer Paper Printing, Wall Paper Printing etc.
2. Tension structures keep the printing material flat.
This solution equipped tension structure on double side, front side and back side, as to keep the printing media flat. Even the artificial loaded media is not in the perfect straight status, this system can automatically correct the skewing in printing process.
3. Efficient dryer
An extra optional Infrared Dryer or Hot Wind Dryer be installed in front of the media so that Textile Printing Ink will be dried instantly before be collected by Automatic Take Up Roller.
4. Printing quality be ensured.
The Media Collecting system and Media Feeding System are run synchronously so that printing quality be ensured. Some stepping problem caused by printing media be solved. There is no force when Pinch Roller of original printer feeding printing media so that printer's life span be extended.
5. Be optimized printer stand as to meet the industrialized production requirements.
Optimized accurate stand is customized by CNC machine. Industrialized production requirements be really meet after optimization.
6. Bulk ink supply system be integrated.
People in Digital Printing industry knows the importance of Ink Supply System. With this CISS, user can not only have similar image quality, but also avoid to use the expensive original inks.
7. Very easy installation process.
End-user can just unlock the Epson printer from it's stand and put it on to this machine and lock it on. Easy done.
Pictures :
| Head | On-demand Piezo head |
| Maxium width | 1,900mm |
| Print resolution | 360,540,720,1440dpi |
| ink | Sublimation ink |
| ink cartridge | 440ml |
| Media size | 210mm-1910mm |
| Media weight | 25kg or under |
| Media Roll diameter | Φ180 mm or under |
| Media take up device | Automatice take-up device |
| interface | USB 2.0 |
| Power Supply | AC100-120V±10%, 50⁄60HZ±1HZ |
| Power consumption | 300W or under |
| Dimension | 2,840x750x1430mm |
| weight | 210kg |
| Print media |
polyester fibre fabric heat transfer paper |
