MHC2-10 Pneumatic Gripper Cylinder-SMC Type Gripper

FOB Price

USD $25 - $30 / Piece

1 Piece(Min.Order)

Supply Ability 500 Piece / Pieces per Month
Port ningbo or shanghai
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Standard or Nonstandard	Standard	Structure	Other, air gripper cylinder
Power	Pneumatic	Body Material	Aluminum
Maximum Stroke	100mm	Shaft Diameter	8-16mm
Place of Origin	Zhejiang, China	Model Number	MHC2-10
Brand Name	CW

Product Description

Specifications

1:MHC2-10 Pneumatic Gripper Cylinder-SMC Type Gripper
2: widely used in machinery.
3:Bore size:10mm.
4:Long service of life.

MHC2-10 Pneumatic Gripper Cylinder-SMC Type Gripper

Features:

1.Same dimensions and sizes as SMC air gripper cylinder.

2.Standard design,simple structure,low starting pressure,smooth motion.

3.Precision grinding piston rod to guarantee long working lifetime.

4.Bore size:10mm,16mm,20mm,25mm

5.Long service of life, easy to control and maintain.

How To Order:

Specification:

Boresize (mm)		10	16	20	25
Fluid		Air
Action		Double acting, Single Acting
Operating pressure	Double Acting	0.1to 0.6 Mpa
	Single Acting	0.25 to 0.6 Mpa
Ambientand fluid temperature		–10 to 60°C
Repeatability		±0.1mm
Max.operating frequency		180 c.p.m.
Cushion		Rubber bumper (Standard, With stroke adjuster)
Lubrication		NoTRequired
Auto Swith (Option)		Solide state switch (3-wire, 2-wire)
Port size		M3x 0.5	M5x 0.8

Model:

Action	Model	Bore size(mm)	Holding momen (effective value)	Operating angle (both sides)	Weight (g)
Double Acting	MHC2-10D	10	0.1	30°to -10 °	39
	MHC2-16D	16	0.39		91
	MHC2-20D	20	0.7		180
	MHC2-25D	25	1.36		311
Single Acting	MHC2-10S	10	0.07		39
	MHC2-16S	16	0.31		92
	MHC2-20S	20	0.54		183
	MHC2-25S	25	1.08		316

Other Pneumatic Air Gripper Cylinders are also available for you:

MHZ2 series Air Gripper

MHL2 series Air Gripper

MHY2 series Air Gripper

MHS2 series Air Gripper

MHT2 series Air Gripper
