Home > Products > Air Gripper > SMC Type MHZ2-20 Parallel Style Air Finger Cylinder
SMC Type MHZ2-20 Parallel Style Air Finger Cylinder
- 500 Piece / Pieces per Month
- ningbo or shanghai
- T/T Credit Card PayPal
Product Details
Standard or Nonstandard: | Standard | Structure: | Other, air gripper cylinder | Power: | Pneumatic |
Body Material: | Aluminum | Maximum Stroke: | 100mm | Shaft Diameter: | 8-16mm |
Place of Origin: | Zhejiang, China | Model Number: | MHZ2-20D | Brand Name: | CW |
Product Description
Specifications
1,SMC Type MHZ2-20 Parallel Style Air Finger Cylinder2,With high precision integral linear guide.
3,With high rigidity.
SMC Type MHZ2-20 Parallel Style Air Finger Cylinder
Features:
1) SMC type parallel air gripper MHZ2 series
2) Built-in magnetic,suitable slot on 2 sides is designed for magnetic sensor fixing
3) With high precision integral linear guide and high rigidity gripper,with good material and cylinder body is machined by advance CNC center,our air gripper are with long life time and easy to mantian.
4) High quality/price rate.
5) Double acting or single acting are all available.
Specification:
6 | 10 | 16 | 20 | 25 | 32 | 40 | ||
Fluid | Air | |||||||
Action | Double acting, Single Acting | |||||||
Operating pressure (Mpa) | Double acting | 0.15 to 0.7 | 0.2 to 0.7 | 0.1 to 0.7 | ||||
Single acting | 0.3 to 0.7 | 0.35 to 0.7 | 0.1 to 0.7 | |||||
Ambient and fluid temperature | –10 to 60°C | |||||||
Repeatability | ±0.01mm | ±0.02mm | ||||||
Max. operating frequency | 180c.p.m. | 60c.p.m. | ||||||
Lubrication | Non-lube | |||||||
Auto Swith (Option) | Solide state switch (3-wire, 2-wire) | |||||||
Port size | M3 x 0.5 | M5 x 0.8 |
Main Material:
No. | Description | Material | Note |
1 | Body | Aluminumalloy | Hardanodized |
2 | Piston | Φ6to Φ16: Stainless steel | Φ20to 40: Hard anodized |
Φ20to Φ40: Aluminum alloy | |||
3 | Lever | Stainlesssteel | Heattreated |
4 | Guide | Stainlesssteel | Heattreated |
5 | Finger | Stainlesssteel | Heattreated |
6 | Rollerstopper | Stainlesssteel | |
7 | Levershaft | Stainlesssteel | Nitriding |
8 | Cap | Φ10,Φ16:Stainless steel | Φ32to 40: Clear anodized |
Φ6,Φ20 to Φ40: Aluminum alloy | |||
9 | Bumper | Urethanerubber | |
10 | Rodseal/Piston seal | NBR |
Other Pneumatic Air Gripper Cylinders are also available for you:
MHZ2 series Air Gripper-SMC Type.
MHL2 series Air Gripper-SMC Type.
MHY2 series Air Gripper-SMC Type.
MHS2 series Air Gripper-SMC Type.
MHT2 series Air Gripper-SMC Type.
1: Usually we ship your order by sea or by air...
2: We do our best to ship your order within 1 week after receiving your payment
3: We'll tell you the tracking number once your order has been sent.
Package
1:Inner packing: opp bag, then carton box for each product.
2:Outer packing: export standard carton, Foam outside protecting the goods against damage
Payment
1: We accept T/T Bank transfer, L/C, Western Union, Moneygram, Paypal.
Why choose us
1: Various style for each products and completely series pneumatic products for you to choose from.
2: Large stock for fast shipping.
3: High quality with competitive price
4: Sample order & small quantity order is ok
6: Provide free products information.
7. Reliable quality assured and active after-sell service
Feel free to contact us at anytime if you have any problems or questions on your purchase. We will resolve any problems such as damaged, not as described, missing parts, and lost items. All emails will be replied within 24 hours except Saturday. & Sunday and Chinese holidays. If you have any other requirements or questions, welcome to visit our website, or just contact with us directly. Thank you!
