ACESEE China supplier ahd ptz 1.4MP/720P/960P 10x zoom mini high speed dome camera
Feature:
- *4.5" AHD Mini High Speed Dome Camera
- 1/3" SONY CMOS Sensor 1.4MP/720P/960P
- Low Illumination, ICR, 3D NR, 16X Digital Zoom
- 10X Optical Zoom (f=5.13mm-46.3mm)
- Weatherproof Outdoor IP66
- *16x6PCS IR LEDS, IR Range: 60m
- *Pan Range: 0°~360° Continue; Tilt Range: 0°~93° Flip
- *Pan Speed: 200°/sec; Tilt Speed: 80°/sec
- *Preset Points: 220
- *Guard Tours: 3 Groups
- *Guard Points: Max.16 points
- *RS485, Pelco D/P supported
- *OSD Menu Available
- *Power Adaptor: DC12V/3A
- *Lightning Protection: Transient Voltage 6000V
- *Size of Package (LxWxH): 28x32x20(cm)
-
*Weight: 3.4Kgs
SPECIFICATION
| Model | APH4A10A130 | ||
| Camera | |||
| Image Sensor | 1/3" SONY CMOS Sensor | ||
| Horizontal Resolution | 720P | ||
| S/N Ratio | >58db | ||
| PTZ | |||
| Horizontal Rotation Speed | 200°/s | ||
| Horizontal Rotation Range | 360° | ||
| Tilt Rotation Speed | 80°/s | ||
| Tilt Rotation Range | 93º | ||
| Auto Flip | Horizontal 180°, Vertical 93° | ||
| Ratio Speed | Support | ||
| 360° Scan | User programmable | ||
| 360° Scan Speed | 01-64speed setting available | ||
| A-B Scan | User programmable | ||
| A-B Scan Speed | 01-64speed setting available | ||
| PWR on Action | Memory/Tour/360 scan/AB scan/Home/Nop | ||
| Park Time | 1-60mins setting available | ||
| Dwell Preset | 1-60s interval available | ||
| Preset Points | 220 | ||
| Go to Preset Speed | 200°/s | ||
| Guard Tours | 3 groups | ||
| Guard Points | Max.16 points, dwell time user selectable | ||
| Auxiliary Interface | |||
| Communication Protocol | Pelco-D, Pelco-P | ||
| Communication | RS485 | ||
| Baud Rate | 1200/2400/4800/9600bps | ||
| General | |||
| Operating Temperature | Indoor: 0°~ +40° Outdoor: -40°~ +60° | ||
| Operating Humidity | ≤95% Non Condensing | ||
| Heater & Blower | Auto temperature control | ||
| Auto Control IR LED | PWM | ||
| OSD Menu | English | ||
| Power | DC12V/3A | ||
| IR Illumination Distance | 60M | ||
| Power Consumption | ≤ 36W | ||
| Lightning Protection | Transient voltage 6000V | ||
| Dimension | 28x32x20(cm) | ||
| Weight | 3.4kgs | ||
You could check the image on PC by our free software CMS
Or on your Phone App : FREEIP
