Specifications
45 Series bridge type plastic cable drag chain1.Type:Bridge type &total closed
2.Material:Nylon6, nylon 66
3. CE certificate
Plastic cable drag chain
(1) Suitable for use in reciprocating motion of the occasion, be able to built-in cable, tubing, trachea, traction and protection of water pipes, etc. play a role.
(2) The drag chain of each section can be open, easy to install and repair. Movement, low noise, wear-resistant, high-speed movement.
(3) The drag chain has been widely used in CNC machine tools, electronic equipment, stone machinery, glass machinery, doors and windows machines, injection molding machines, mechanical hands, overweight transportation equipment, automated warehouses.
45 Series
|
Model |
Inside Dimension |
Outside Dimension |
Bending Radius (mm) |
Pitch (mm) |
Non-support Length(m) |
TL1-45.50 |
45×50 |
67×81 |
75,100, 125,150, 200,250,300 |
70 |
4 |
TL1-45.60 |
45×60 |
67×91 |
70 |
4 |
|
TL1-45.75 |
45×75 |
67×106 |
70 |
4 |
|
TL1-45.100 |
45×100 |
67×131 |
70 |
4 |
|
TL1-45.125 |
45×125 |
67×156 |
70 |
4 |
|
TL1-45.150 |
45×150 |
67×181 |
70 |
4 |
|
TL1-45.175 |
45×175 |
67×206 |
70 |
4 |
|
TL1-45.200 |
45×200 |
67×231 |
70 |
4 |
|
Type |
Bridge type, Bottom lids can be opened |
||||
Model |
Inside Dimension |
Outside Dimension |
Bending radius (R) |
Pitch (mm) |
Non-support Length(m) |
TL2-45.50 |
45×50 |
66×82
|
100.125 |
68 |
3.5 |
TL2-45.60 |
45×60
|
66×93
|
68 |
3.5 |
|
TL2-45.75 |
45×75
|
66×108
|
68 |
3.5 |
|
TL2-45.100 |
45×100
|
66×133
|
68 |
3.5 |
|
TL2-45.125 |
45×125
|
66×158
|
68 |
3.5 |
|
TL2-45.150 |
45×150
|
66×183
|
68 |
3.5 |
|
TL2-45.175 |
45×175
|
66×208
|
68 |
3.5 |
|
TL2-45.200 |
45×200
|
66×233
|
68 |
3.5 |
|
TL2-45.250 |
45×250
|
66×288
|
68 |
3.5 |
|
TL2-45.275 |
45×275
|
66×308
|
68 |
3.5 |
|
TL2-45.300 |
45×300
|
66×333
|
68 |
3.5 |
|
Type |
Bridge type, Bottom lids can be opened |
||||
Packaging detail: 1.Carbon+woven bag in standard exporting boxes.
2. As client's requirement.
3. Pallets are available if it is necessary.
Small order are accepted by us. ( If you need small quantity, but need urgent, we can delivery them by follow express)
