Home > Electrical & Electronics > Connector & Terminals > Wire to Wire Connector > EB-6009 BNC JACK TO F PLUG

EB-6009 BNC JACK TO F PLUG

Name: EB-6009 BNC JACK TO F PLUG
Brand: eastron
SKU: 126276791
Availability: InStock

US$ 0.1 - 0.11 MOQ: 5 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

eastron

Model Number:

EB-6009 BNC JACK TO F PLUG

Contact Supplier Request Quote Chat Now

Eastron Electronics Company Limited (Zhongshan)

Payment & Shipping

Payment Methods:

Port of Shipment:

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name eastron

Model Number EB-6009 BNC JACK TO F PLUG

Type BNC

Application RF

Gender Male

Specifications

BNC connector female for cable crimping
1)Brass with gold or nickel plated
2)small contact resistance
3)IEC60169 standard

solderless connector are popular for cable

Coaxial connector, RF connector, BNC connectors are designed to provide high electrical performance for microwaveapplications up to 12GHZ.BNC connectors ensure quick locked and excellent durability and mechanical strength.

BNC male twist on for cable

Body	brass	Nickel or gold plated
insulator	PTFE
Contact	brass	Gold plated thickness >8u”

1. ELECTRICAL

Impedance: 75W nominal

Frequency Range: 0~4GHz

Rating Voltage: 500V

Dielectric Withstanding Voltage: 1500V

Contact Resistance: 3.0 mW MAX

Insulation Resistance: 5000 MW MIN.

2. GENERAL CHARACTERISTICS

Storage Temperature: -40°C to 85°C

3. RELIABILITY

DURABILITY: >500 CYCLES

SALT SPRAY TEST: APPEARANCE OK & CONTACT RESISTANCE 40mW max. (Exposed to salt mist conditions: concentration 5±1%, PH: 6.5-7.2, cycle is 13’s spray, 11’s stop, temp is 35±2°C, time: 8 hours.)

4. Rohs:

All the components of this connector are compliant with European directive 2002/95/CE”.

BNC connectors are characterized by their 2-stud quick connect/disconnect bayonet coupling arrangement.

They are one of the most popular of the coaxial connector and are suitable for a wide range of systems,including Radio Telecommunication systems,Medical Equipment,Computer Networks,Safety&Security and test instrumentation.Available in 50Ω,75Ω,and 50Ω reverse polarity.

Product Group

Production Line View

Quality

QC/Technical Support We possess digital calipers, digital micrometers, thread and pin gauges, tool microscopes, pitch diameter micrometers, height gauges, profile projectors, hardness testers, ohm testers and push/pull testers.
