Help CenterGarage Door Opener
Related Products
1) Micro intellectual control
A. 1 button control open, stop & close
B. Light is on when opening or closing the door
C. Light automatic off after 3 minutes later
D. Overload, over hot, low power input protection
E. The door pauses momentarily then rebounds
2) DC motor
Low noise, soft start, slow stopping
3) LED display
Working situation be shown on the LED screen
4) Decoding
Rolling code
5) Manual disengagement
Open & close by hand w/o power
6) Optional functions
A. photocell
B. Battery back-up
C. Wall switch
| Power Input | AC 220V ±10%, 50~60Hz |
| Motor | DC 24V |
| Working temperature | >-20°c,<+50°c |
| Relative Humidity | ≤90% |
| Open&Close force | 800N,1000N,1200N |
| Reception Frequency | 433.92MHZ |
| Decoding | Rolling Code |
| Transmitter Power | 27A 12V Battery |
| Globe | 24V 5W |
| Courtesy Light Time | 3minutes |
Motor Head: 1set/ box, 4sets/Carton
Motor Shaft: 1pc/box,2pcs/pack
Motor shaft length: door height + 900mm (options: 3m, 3.3m, 3.6m,3.9m~~)
Loading: 900sets/20GP N.W.:12600kgs, G.W.:13500ks
Certificate: CE
Warranty: 1 Year
