Swing Gate Operator Automatic Swing Gate Opener
US$ 10 - 200
MOQ: 50 Sets
Key Specifications
Get Latest Price
Brand Name:
XUFENG
Model Number:
XFD-II
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
XUFENG
Model Number
XFD-II
Product Description
A. Built-in control board ( External control board is available)
B. Mechanical limit switch
C. Two control boards can communicate each other
D. 24DC back-up battery can be input
E. Optional terminals: Push Botton, Photocell,Flash Lamp
F. In case of power failure, release the clutch easily, and operate the gate manually
Technical Data
| 1# | Supply Voltage | AC220V ±10% |
| 2# | Motor Power | 50W x 2 |
| 3# | Current | 2.5A |
| 4# | Rotational Speed | 1400RPM |
| 5# | Rod's running speed | 1.6cm/2s |
| 6# | Rod's Max Travel | 300mm |
| 7# | Max. single-leaf length | 3m |
| 8# | Max. single-leaf weight | 300kgs |
| 9# | Environment temperature | -20°c~+50°c |
| 10# | Protection Class |
IP55
|
