Home > Auto, Motorcycle Parts & Accessories > Car Safety > Car Rearview Camera > 5 Inch Car Backup Camera System With Touch Panel Monitor

5 Inch Car Backup Camera System With Touch Panel Monitor

5 Inch Car Backup Camera System With Touch Panel Monitor photo-1
Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Other, Reverse Camera System
Voltage:
DC 12V
Car Make:
all kinds
Payment & Shipping
Payment Methods:
Port of Shipment:
GUANGZHOU
Delivery Detail:
Delivery time depends on order quantity.
Type Other, Reverse Camera System
Voltage DC 12V
Car Make all kinds
Place of Origin Guangdong, China
Brand Name OEM
Model Number MO-119D,CW-644,CS-404

5 Inch car backup camera system with touch panel monitor

5Inch car backup camera system Features:

5 Inch TFT LCD color monitor with digital screen
Control the monitor with finger tips on the touch button system
TFT LCD monitor with wide view angle and high resolution display.
Picture image adjustable for Horizontal, Vertical, Mirror and Normal viewing
8 languages selectable for user operation
Automatic backlighting for buttons.
Full-function remote control.
Multiple video formats available: AUTO/ PAL/ NTSC.
Up to 3 AV inputs.
On-board speaker.
Operates from 10 - 32V. Supports 12V or 24V automobile battery.
Automatically switches to back-up, left or right side camera views.



5 Inch car backup camera system with touch panel monitor

5 Inch car backup camera system with touch panel monitor

5 Inch car backup camera system with touch panel monitor




5" TFT- LCD color monitor with digital screen - MO-119D
Product: 5" TFT LCD color monitor with digital screen
Audio output: 1W.
Loudspeaker: one 4.0cm round loudspeaker.
Power supply: Automobile storage battery (10-32V).
Power consumption: about 5W .
Outer dimension: 156mm(W) x 107mm (H) x 32mm (T)
Dot pitch: 0.0529(H) × 0.1587 (V).
Resolution: 640 x 3(RGB) x 480 .
Color depth:24 bit
Display colors:16.7M dithering.
Contrast: 500:1.
Brightness: 200cd/m².
Viewing angle: U: 50° / D: 70°, R/L: 70°/ 70°.
Operating temperature: -20 ºC ~+70ºC,RH90%.
Storage temperature: -30 ºC ~+80ºC,RH90%.

5 Inch car backup camera system with touch panel monitor5 Inch car backup camera system with touch panel monitor5 Inch car backup camera system with touch panel monitor







Camera features(CS-404):
Compact profile
Waterproof and vandalproof
Convenient angle adjustment
Infrared LED light: 5
IR Distance: 5 m
High resolution
Can be mounted on rear or either side of vehicles



5 Inch car backup camera system with touch panel monitor5 Inch car backup camera system with touch panel monitor5 Inch car backup camera system with touch panel monitor5 Inch car backup camera system with touch panel monitor



5 Inch car backup camera system with touch panel monitor





Camera features(CW-644):
Compact profile
Waterproof and vandalproof
Convenient angle adjustment
Infrared LED light: 5
IR Distance: 5 m
High resolution
Can be mounted on rear, front, or either side of vehicles

5 Inch car backup camera system with touch panel monitor5 Inch car backup camera system with touch panel monitor





5 Inch car backup camera system with touch panel monitor
