Help CenterCCTV Waterproof ir Dome Camera With High Resolution
Related Products
-
Weatherproof Security CCTV Camera,Color Dome CameraNegotiableMOQ: 1 Piece -
Sea Snail Shape Waterproof IR Ccd CCTV CameraNegotiableMOQ: 1 Piece
-
High Speed High Resolution Waterproof IR Ccd Dome CamerasNegotiableMOQ: 1 Piece
-
Sea Snail Shape Waterproof IR Ccd Dome CameraNegotiableMOQ: 1 Piece
-
Sea Snail Vandal Proof IR Dome Small Car CameraNegotiableMOQ: 1 Piece
CCTV waterproof ir dome camera Features:
1) Waterproof and anti-vandal housing
2) Weather resistant
3) Compact profile
4) 24 IR LEDs
5) IR Distance: approx. 20m
6) High resolution
Specifications:
1/3" color CMOS sensor:
1) Without audio
3) TV system: PAL / NTSC
4) Effective pixels: 628 x 582 pixels / 510 x 492 pixels
5) Sensing area: 5.78 x 4.19 / 4.69 x 3.54mm
6) Scanning system: 2:1 interlace
7) Sync. system: internal
8) Resolution: 380TV lines
9) Horizontal sync. frequency: 15.625kHz / 15.734kHz
10) Vertical sync. frequency: 50Hz / 60Hz
11) Minimum illumination: 0LUX / F1.2 with IR
12) Video output: 1.0Vp-p, 75ohm
13) Gamma consumption: 0.45
14) AGC: auto
15) S/N ratio: better than 48dB
16) White balance: auto
17) Electronic shutter: 1/60 - 1/15,000 seconds
18) BLC: auto
19) Current consumption: 200mA
20) Power supply: DC 12V
21) Operating temperature: -10 - 46°C, RH 95% max.
22) Storage temperature: -30 - 60°C, RH 95% max.
23) Lens: f = 6.0mm/3.6mm, F = 2.0
24) Lens angle: 69/92 (N), 80/110 (P)
1/3" B/W CCD sensor:
1) Without audio
2) Image device: Samsung
3) TV system: CCIR/ EIA
4) Effective pixels: 500 x 582 pixels / 510 x 492 pixels
5) Sensing area: 4.9 x 3.7mm
6) Scanning system: 2:1 interlace
7) Sync. system: internal
8) Resolution: 420 TV lines
9) Horizontal sync. frequency: 15.625kHz / 15.734kHz
10) Vertical sync. frequency: 50Hz / 60Hz
11) Minimum illumination: 0lux/F1.2 with IR
12) Video output: 1.0Vp-p, 75 ohms
13) Gamma consumption: 0.45
14) AGC: on
15) S/N ratio: better than 48dB
16) White balance: auto
17) Electronic shutter: 1/60 (CCIR) / 1/50 (EIA) - 1/10,000 seconds
18) BLC: auto
19) Current consumption: 300mA
20) Power supply: DC 12V
21) Operating temperature: -10 - 55°C (CCIR), or 60°C (EIA), RH 95% max.
22) Storage temperature: -20 - 60°C, RH 95% max.
23) Lens: f=3.6mm / F = 2.0
24) Lens angle: 92 degrees
1/4" color CCD sensor:
1) Without audio
2) Image device: sharp
3) TV system: PAL / NTSC
4) Effective pixels: 512 x 582 pixels / 512 x 492 pixels
5) Sensing area: 3.6mm x 2.7mm
6) Scanning system: 2:1 interlace
7) Sync. system: internal
8) Resolution: 420 TV lines
9) Minimum illumination: 0lux / F1.2 with IR
10) Horizontal sync. frequency: 15.625kHz / 15.734kHz
11) Vertical sync. frequency: 50Hz / 60Hz
12) Video output: 1.0Vp-p, 75 ohms
13) Gamma consumption: 0.45
14) AGC: auto
15) S/N ratio: better than 48dB
16) White balance: auto
17) Electronic shutter: 1/60(NTSC) / 1/50(PAL) - 1/10,000 seconds
18) BLC: auto
19) Current consumption: max. 300mA
20) Power supply: DC 12V
21) Operating temperature: -20 - 70°C, RH95% max.
22) Storage temperature: -40 - 85°C, RH95% max.
23) Lens: f=3.6mm / F=2.0
24) Lens angle: 69 degrees
Testing Standard: MIL-STD-105E
Tests
Manufacturing Process
Tests
FAQ
Q: What is the MOQ ?
A: 1 peice
Q: How fast for sample delivery?
A: 3-7 days
Q: Can I get a lower price if I order large quantities?
A: Yes, the larger the quantity, the cheaper the prices.
Q: How about the warranty period?
A: One year!
Q: How can you guarantee the quality?
A: Our production quality follows the standard of MIL-STD-105E. We have a QC team with 12 years’ experience. All of the products will run through over 4 times’ 100% testing before being delivered.
