Waterproof IR Ccd Super Mini Cctv Camera

Waterproof IR Ccd Super Mini Cctv Camera thumbnail-1
Waterproof IR Ccd Super Mini Cctv Camera photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
OEM
Model Number:
CD-069
Style:
Dome Camera
Contact Supplier Request Quote Chat Now
Sharpvision Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name OEM
Model Number CD-069
Style Dome Camera
Sensor CCD
Technology Infrared
Special Features Vandal-proof





  waterproof IR ccd hidden camera Features:



  • Compact profile
  • Waterproof and anti-vandal housing
  • Hard ceiling or suspended ceiling applications
  • 5 IR LEDs
  • IR Distance: 3~5 m
  • High resolution



COLOR CCD CAMERA SPECIFICATION



  • Image Device: 1/3SONY Super HAD CCD
  • TV System: PAL/NTSC
  • Total Number Of Pixels: PAL: 537 (H) × 597(V) / NTSC: 537(H) × 505(V)
  • Effective Pixels: PAL:500(H) × 582(V) / NTSC:510(H) × 492(V)
  • Sensing Area: 4.9mm(H) × 3.7mm(V)
  • Sync. System: Internal
  • Resolution: 420 TV Lines
  • Minimum Illumination: 0Lux (Infrared lamps on) 0 .05Lux(day) / F1.2
  • Video Output: : Composite Signal (1.0Vp-p, 75Ω)
  • Gamma Correction: 0.45
  • AGC: ON
  • S/N Ratio: Better than 48dB
  • White Balance: Auto
  • Electronic Shutter : 1/50-1/100,000Sec 1/60-1/100,000Sec
  • BLC: Auto
  • Current Consumption: Max. 300A
  • Power Supply: DC12V
  • Operating Temperature: -20~ 70 RH95% Max
  • Storage Temperature: -40~ 80 RH95% Max
  • Lens: 2.8mm, 3.6mm Optional
  • Lens Angle: 120° ,92°




waterproof IR ccd super mini cctv camerawaterproof IR ccd super mini cctv camerawaterproof IR ccd super mini cctv camerawaterproof IR ccd super mini cctv camera








Recommended Products

 waterproof IR ccd super mini cctv camera











Certificates

 waterproof IR ccd super mini cctv camera



Why Choose Us?

 waterproof IR ccd super mini cctv camera



Quality Control Flow Chart



Testing Standard: MIL-STD-105E

waterproof IR ccd super mini cctv camera



Tests

 waterproof IR ccd super mini cctv camera

Manufacturing Process
Tests



  waterproof IR ccd super mini cctv camera



FAQ



Q: What is the MOQ ?
A: 1 peice



Q: How fast for sample delivery?
A: 3-7 days



Q: Can I get a lower price if I order large quantities?
A: Yes, the larger the quantity, the cheaper the prices.





Q: How about the warranty period?
A: One year!



Q: How can you guarantee the quality?
A: Our production quality follows the standard of MIL-STD-105E. We have a QC team with 12 years’ experience. All of the products will run through over 4 times’ 100% testing before being delivered.
