Weatherproof Security Cctv Camera ir Dome

Weatherproof Security Cctv Camera ir Dome thumbnail-1
Weatherproof Security Cctv Camera ir Dome photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OEM
Model Number:
CD-062
Contact Supplier Request Quote Chat Now
Sharpvision Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name OEM
Model Number CD-062
Style Dome Camera
Sensor CMOS
Technology Infrared
Special Features Vandal-proof
Type Other, cctv camera ir dome

Weatherproof Security cctv camera ir dome

Weatherproof Security cctv camera ir dome

 cctv camera ir dome Features:


1) Waterproof and anti-vandal housing
2) Weather resistant
3) Compact profile
4) 24 IR LEDs
5) IR Distance: approx. 20m
6) High resolution

Specifications:


1/3" color CMOS sensor:


1) Without audio
2) Image device: OV7910
3) TV system: PAL / NTSC
4) Effective pixels: 628 x 582 pixels / 510 x 492 pixels
5) Sensing area: 5.78 x 4.19 / 4.69 x 3.54mm
6) Scanning system: 2:1 interlace
7) Sync. system: internal
8) Resolution: 380TV lines
9) Horizontal sync. frequency: 15.625kHz / 15.734kHz
10) Vertical sync. frequency: 50Hz / 60Hz
11) Minimum illumination: 0LUX / F1.2 with IR
12) Video output: 1.0Vp-p, 75ohm
13) Gamma consumption: 0.45
14) AGC: auto
15) S/N ratio: better than 48dB
16) White balance: auto
17) Electronic shutter: 1/60 - 1/15,000 seconds
18) BLC: auto
19) Current consumption: 200mA
20) Power supply: DC 12V
21) Operating temperature: -10 - 46°C, RH 95% max.
22) Storage temperature: -30 - 60°C, RH 95% max.
23) Lens: f = 6.0mm/3.6mm, F = 2.0
24) Lens angle: 69/92 (N), 80/110 (P)

1/3" B/W CCD sensor:


1) Without audio
2) Image device: Samsung
3) TV system: CCIR/ EIA
4) Effective pixels: 500 x 582 pixels / 510 x 492 pixels
5) Sensing area: 4.9 x 3.7mm
6) Scanning system: 2:1 interlace
7) Sync. system: internal
8) Resolution: 420 TV lines
9) Horizontal sync. frequency: 15.625kHz / 15.734kHz
10) Vertical sync. frequency: 50Hz / 60Hz
11) Minimum illumination: 0lux/F1.2 with IR
12) Video output: 1.0Vp-p, 75 ohms
13) Gamma consumption: 0.45
14) AGC: on
15) S/N ratio: better than 48dB
16) White balance: auto
17) Electronic shutter: 1/60 (CCIR) / 1/50 (EIA) - 1/10,000 seconds
18) BLC: auto
19) Current consumption: 300mA
20) Power supply: DC 12V
21) Operating temperature: -10 - 55°C (CCIR), or 60°C (EIA), RH 95% max.
22) Storage temperature: -20 - 60°C, RH 95% max.
23) Lens: f=3.6mm / F = 2.0
24) Lens angle: 92 degrees

1/4" color CCD sensor:
1) Without audio
2) Image device: sharp
3) TV system: PAL / NTSC
4) Effective pixels: 512 x 582 pixels / 512 x 492 pixels
5) Sensing area: 3.6mm x 2.7mm
6) Scanning system: 2:1 interlace
7) Sync. system: internal
8) Resolution: 420 TV lines
9) Minimum illumination: 0lux / F1.2 with IR
10) Horizontal sync. frequency: 15.625kHz / 15.734kHz
11) Vertical sync. frequency: 50Hz / 60Hz
12) Video output: 1.0Vp-p, 75 ohms
13) Gamma consumption: 0.45
14) AGC: auto
15) S/N ratio: better than 48dB
16) White balance: auto
17) Electronic shutter: 1/60(NTSC) / 1/50(PAL) - 1/10,000 seconds
18) BLC: auto
19) Current consumption: max. 300mA
20) Power supply: DC 12V
21) Operating temperature: -20 - 70°C, RH95% max.
22) Storage temperature: -40 - 85°C, RH95% max.
23) Lens:  f=3.6mm / F=2.0
24) Lens angle: 69 degrees



Weatherproof Security cctv camera ir dome

Weatherproof Security cctv camera ir domeWeatherproof Security cctv camera ir domeWeatherproof Security cctv camera ir domeWeatherproof Security cctv camera ir domeWeatherproof Security cctv camera ir dome






Recommended Products

 Weatherproof Security cctv camera ir dome











Certificates

 Weatherproof Security cctv camera ir dome



Why Choose Us?

 Weatherproof Security cctv camera ir dome



Quality Control Flow Chart



Testing Standard: MIL-STD-105E

Weatherproof Security cctv camera ir dome



Tests

 Weatherproof Security cctv camera ir dome

Manufacturing Process
Tests



  Weatherproof Security cctv camera ir dome



FAQ



Q: What is the MOQ ?
A: 1 peice



Q: How fast for sample delivery?
A: 3-7 days



Q: Can I get a lower price if I order large quantities?
A: Yes, the larger the quantity, the cheaper the prices.





Q: How about the warranty period?
A: One year!



Q: How can you guarantee the quality?
A: Our production quality follows the standard of MIL-STD-105E. We have a QC team with 12 years’ experience. All of the products will run through over 4 times’ 100% testing before being delivered.
