1. Application of 3x1.5mm2 Cu/XLPE/LSOH fire-resistant Power Cable :
A power cable is an assembly of one or more electrical conductors, usually held together with an overall sheath. The assembly is used for transmission of electrical power. Power cables may be installed as permanent wiring within buildings, buried in the ground, run overhead, or exposed.
Flexible power cables are used for portable devices, mobile tools and machinery.
2. Material Standard of 3x1.5mm2 Cu/XLPE/LSOH fire-resistant Power Cable :
Conductor: Solid or stranded copper
Insulation: Cross-linked polyethylene (XLPE) or Polyvinyl chloride (PVC)
Filler: Polypropylene filament with lapped binding tape
Binder: Binding tape
Inner sheath: Polyvinyl chloride (PVC)
Amour: Galvanized steel wire armored(SWA) or steel tape armored(STA)
Sheath: Polyvinyl chloride (PVC)
3. Executive standard 3x1.5mm2 Cu/XLPE/LSOH fire-resistant Power Cable
IEC60502,and BS6346, VDE, AS/NZS, UL,etc or as customer's request.
| Type |
Name
|
Application | |
|
Cu Conductor |
Al Conductor |
||
|
YJV YJY |
YJLV YJLV |
XLPE Insulated,PVC or PE S heathed Power Cable | For laying in door,tunnel,channel and underground.Unable to bear external mechanical force,but bear the traction force during laid. |
|
YJV22 YJV23 |
YJLV22 YJLV23 |
XLPE Insulated,Steel Tape Armoured,PVC or PE Sheathed Power Cable |
For laying in tunels in door,tunnel,channel and underground.Able to bear external mechanical force,but unable to bear large pulling force. |
|
YJV32 YJV33 |
YJLV32 YJLV33 |
XLPE Insulated,Fine Steel Wire Armoured,PVC or PE Sheathed Power Cable |
For laying in shaft with large difference of level.Able to bear external mechanical force,and moderable pulling force. |
|
YJV42 YJV43 |
YJLV42 YJLV43 |
XLPE Insulate,Thick Steel Wire Armoured,PVC or PE Sheathed Power Cable |
Able to bear positive pressure and pulling force |
Conductor Properties |
Copper Conductor |
Al conductor Class 1 |
Al conductor Class 2 |
AA8030 |
|
|
Physical Properties |
Density(g/mm²) |
8.9 |
2.703 |
2.703 |
2.703 |
Expansion coefficient |
17×10-6 |
23×10-6 |
23×10-6 |
23×10-6 |
|
Heat transfer coefficient |
0.94 |
0.53 |
0.53 |
0.53 |
|
Resistivity(Ω·mm²/m) |
0.017241 |
0.028264 |
0.028264 |
0.027454 |
|
TCR (0~100°C) |
0.00393 |
0.00403 |
0.00403 |
0.00403 |
|
Conductivity (IACS%) |
100 |
61 |
61 |
62.8 |
|
|
Mechanical Properties |
Tensile Strength(MPa) |
220~270 |
150~210 |
70~110 |
110~130 |
Yield Strength(MPa) |
30~45 |
120~170 |
20~30 |
65 |
|
Elongation (%) |
30~45 |
0.5~2.0 |
23~25 |
25~30 |
|
Material content in the earth |
<0.01% |
8% |
8% |
8% |
|
4. Picture show 3x1.5mm2 Cu/XLPE/LSOH fire-resistant Power Cable :
3x1.5mm2 Cu/XLPE/LSOH fire-resistant Power Cable .
International wooden drums or as your requirement.
Henan Huadong Cable Group is a joint stock enterprise that integrated in cable production, research & development,and domestic & international trade in China.
Zhengzhou Hongliang Cable Co.,ltd is one of the branch of Huadong Cable?Group ,and also is biggest professional import and export trade company in China.
The plant was founded in 1998,and occupied 50,000 square meters,with advanced equipments of 20 sets production lines and 25 sets testing machines,Annual production capacity is more than 12 million kilometers.
Our international branch is located in Zhengzhou city,which is well-known for convenient transportation . We mainly produce and export all aluminum conductor(AAC), aluminum conductor steel reinforced(ACSR), all aluminum alloy conductor(AAAC), overhead Aerial bundled ABC cable,1-66kV power cables(including XLPE insulated cables, PVC insulated cables, SWA/STA armored cables).(XLPE/PVC insulated ABC cable),control cables, welding cables, rubber cables ,mining cables and electrical wires(PVC sheathed flexible cable). These cables can be used for power transmission in air,underground and industry,such as power station, railway, agriculture, and estate. Our products honoured I S O 9 0 0 1:2 0 0 2 and CCC,PCCC,SGS,BV certificates. We strictly according to GB,IEC,BS,ICEA, ASTM, DIN, VED, JIS standards to manufacture the products, and also we can design and produce according to customers' requirements.We have exported wires and cables to European, South America, North America, Middle East, Africa, Asia,,Oceania countries and etc.
Reach wires xlpe pv dc tinned copper solar power cable 16 mm2 .
1.Quality is our culture. we are one of the most famous brand in China. Quality is verified by clients.
2. High-effiency oversale team makes your business much easier.
3. free samples are available for further evaluation and you are highly welcome to visit our factory anytime!
1.what is our payment term ?
Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.
2.what is the lead time ?
The lead time usually is 10 - 30 working days.
3.what is the package of the cable ?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.
4.Could we provide the free sample for customer ?
Sure, we provide the free sample for customer to checking.
