KCD type wire rope electric crane hoist for construction
1. Capacity: 300/600kg, 400/800kg, 500/1000kg,750/1500/kg
2. Standard lift: 30/60/100 meters
3. Voltage: 380v for 300/600kg, 500/1000kg and 750/1500kg
220v for 400/800kg
Specifications
Model |
Usage |
Voltage(V) |
Power(kw) |
Rated Load(kg) |
Lifting Speed(m/min) |
Lifting Height(m) |
Rope Dia(mm) |
Net Weight(kg) |
300-600 |
Single-hook |
380 |
0.6 |
300 |
16 |
30-60 |
5 |
34 |
Double-hook |
600 |
8 |
||||||
400-800 |
Single-hook |
220 |
1.1 |
500 |
14 |
30-100 |
6 |
49 |
Double-hook |
1000 |
7 |
||||||
500-1000 |
Single-hook |
380 |
1.5 |
500 |
14 |
30-100 |
6 |
55 |
Double-hook |
1000 |
7 |
||||||
750-1500 |
Single-hook |
380 |
1.5 |
750 |
14 |
30-100 |
7.7 |
65 |
Double-hook |
1500 |
7 |
Pictures of product
Picture of parts
Hebei sanlong crane & hoist Machinery Co., LTD. was founded in 2007, with registered 10 million RMB. Our company currently employs over 200 people and there are more than 50 experienced technical personnel among them. The factory covers and area of 260 acres, with the modern technical equipement. And we have the CE certifications and ISO certifications. And we have a big market all over the world, including Eurepo, America, South America, Austrilia, the middle East, Russsia and India.
1. Our main items: HSZ/ HSC/VITAL/DK chain block, HSH/ VITAL lever hoist, KCD multifunction motor hoist, PA/CD1 electric wire rope hoist etc.
2. Company history: Our factory are founded in 2005.
3. Major market: Middle east, South America & Southeast Asia.
4. Company property: Factory, not trading company.
