1ton HS Type Chain Pulley Block

Name: 1ton HS Type Chain Pulley Block
Brand: BDSLO or OEM
SKU: 126234303
Availability: InStock

US$ 15 - 85 MOQ: 10 Pieces

Key Specifications

Condition:

New

Place of Origin:

Hebei, China

Brand Name:

BDSLO or OEM

Hebei Sanlong Crane & Hoist Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin/ Shanghai/ Qingdao/Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Hebei, China

Brand Name BDSLO or OEM

Model Number HSZ

Usage Construction Hoist

Power Source Hand Chain

Sling Type Chain

Maximum Lifting Weight 20 t

Maximum Lifting Height 12 meters

Lift Speed according to hand pulling force

Certification CE/ISO/GS

Warranty 12 months

After-sales Service Provided No overseas service provided

Feacturs:

1. Small size & light weight.

2.Grade 80 20Mn2 alley steel chain.

3.Fully forged hooks.

4. Package: carton/ wooden box.

5.CE approved.

6.Manufacturer supply with competitive price & good quality.

Specifications:

Model		HSZ-0.5	HSZ-1	HSZ-1.5	HSZ-2	HSZ-3	HSZ-5	HSZ-10	HSZ-20
Capacity (ton)		0.5	1.0	1.5	2	3	5	10	20
Standard Lifting Height (M)		2.5	2.5	2.5	2.5	3	3	3	3
Test Load (ton)		0.63	1.25	2	2.5	4	6.3	12.5	25
Headroom (drawn close up)Hmin(mm)		270	270	368	444	486	616	700	1000
Hand Chain Force (n)		225	309	343	314	343	383	392	392
Number of Chains (row)		1	1	1	2	2	2	4	8
Diameter of load chain (mm)		6	6	8	8	8	10	10	10
Dimension (mm)	A	120	142	178	142	178	210	358	580
	B	108	122	139	122	139	162	162	189
	C	24	28	34	34	38	48	64	82
	D	120	142	178	142	178	210	210	210
N.W. (kg)		9.5	10	16	14	24	36	68	155
G.W. (kg)		12	13	20	17	28	45	83	193
Packing (cm) LWH		282117	302418	342920	332519	383020	453524	625028	704675
Extra weight per m of extra lift (kg)		1.7	1.7	2.3	2.5	3.7	5.3	9.7	19.4
