AMEISON 2400 - 2500 MHz Directional Base Station Sector 120 Degree 16dbi Wifi Panel Antenna

AMXP-2425VH-D16L120

Electrical Specifications

Frequency range(MHz)

2400~2500

Polarization

Vertical and Horizontal

Gain(dBi)

2×16

half-power beam width(°)

H:120   V:7

Front-to-back ratio(dB)

≥18

Input Impedance(Ω)

50

VSWR

≤1.5

Isolation between ports

≥28dB

Cross-polar ratio

≥15dB@0º     ≥10dB@+/-60º

Sidelobe suppression for first sidelobe above horizon

15 dB

Maximum input power(W)

200

Lightning protection

DC Ground

Mechanical Specifications

Input connector type

2-N Female

Dimensions-mm (Height/Width/Depth)

1200*114*54

Packing size(mm)

 1280*155*145

Antenna weight (kg)

6

Radome material

UPVC

Radome color

Gray

Mechanical tilt(°)

0~10

Operating temperature(°c)

-40~60

Rated Wind Velocity(m/s)

60

Waterproof Standard

IP67

Mounting way

pole-holding

Mounting hardware(mm)

35 ~ 75
