AMEISON 1710 - 2170 MHz Directional Wall Mount Flat Patch 14dBi 1900mhz directional antenna
AMXW-1722-14B
Feature:
High gain, strong anti-interference ability
Good defense system
Full day working
Exquisite appearance
Optimized dimension
Application:
WCDMA/ PCS/ 3g/ 4g LTE system
Wireless communication and datatransmission system
AMXW-1722-14B Electrical Specifications | |
Frequency range(MHz) | 1710-2170 |
Bandwidth(MHz) | 460 |
Gain(dBi) | 14 |
Half-power beam width(°) | H:30 V:30 |
VSWR | ≤2.0 |
Input Impedance(Ω) | 50 |
Polarization | Vertical |
Maximum input power(W) | 50 |
Lightning protection | DC Ground |
Input connector type | SMA Male or Requested |
Mechanical Specifications | |
Dimensions-mm (Height/Width/Depth) | 225*195*47 |
Antenna weight(kg) | 0.45 |
Operating temperature(°c) | -40~60 |
Rated Wind Velocity(m/s) | 60 |
Radome material | ABS |
Radome color | white |
Waterproof Standard | IP54/ IP65/ IP67 |
Mounting way | Wall-mounted/ Pole-holding |
Mounting hardware(mm) | 35 - 50 |
