Material Handling Equipment

Material Handling Equipment thumbnail-1
Material Handling Equipment photo-1
US$ 1,750 - 2,250 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Elevation Speed:
5.5 sec
Vertical Travel(mm):
650 mm
Contact Supplier Request Quote Chat Now
Guangdong Bo Langte Intelligent Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Elevation Speed 5.5 sec
Vertical Travel(mm) 650 mm
Horizonal Travel(mm) 120 mm
Application Other, Take out Product
Place of Origin Guangdong, China
Brand Name BORUNTE
Model Number BRP650V
Weight 36/49 kg
Dimension(L*W*H) 570*1320 mm
Power(W) 400W
Certification CE, SGS, TUV, ISO 9001: 2008
Warranty One year
After-sales Service Provided Engineers available to service machinery overseas

Material Handling EquipmentMaterial Handling Equipment

1.BRP series Swing-arm Robot is applicable to all types of horizontal injection machines

   for take-out products and sprues.

2.Single stage and telescopic type arms.

3.After installed robot, the productivity will be increased, and also reduce defective rate,

   ensure safty of operators, reduce manpower and accurately control the output to reduce

   waste.

Material Handling Equipment

Main Specification:

Model BRP650V BRP850WV
Recommended I.M.M(ton) 30-180 150-280
Vertical Stroke(mm) 650 850
Crosswise stroke(mm) 120 120(175)
Swing Angle(degree) 60-90
Dry Take Out Time(sec) 0.9 1.1
Max.Loading(kg) 3
Dry Cycle Time(sec) 5.5 6
Air Consumption(Nl/cycle) 1.5 2
Net Weight(kg) 36/49 50

Outer Dimensions:

Model A B C D E F G H I J K
BRP650V 1320 1190 510 570 / 210 / 50 440 / /
BRP850WV 1250 1000 180 130 435

Controller:

1.Palm controller with dialogue type operation interface, the display language is changeable,

    easy for learn.

2.Eight sets built-in programs, with L/U take out function.

3.Applicable to all types of products take out.

4.Traverse stroke can be used to place products in multiple points(99 points at most) to

    stacking products.



High Quality End-of-Arm Toolings and Parts:Material Handling Equipment





Customers Application Cases:

Material Handling Equipment





Packaging Details:Material Handling Equipment





Certifications:

Material Handling Equipment





Our Advantages:

1.Manufacturer: We have our own plant and production equipment.

2.Technology: Professional R&D team, complete production equipment and perfect testing

     technology.

3.Provide a competitive price, and we can meet your specific needs for the machinery.





Please feel free to contact us for more information,

what we want is your satisfictions!
