Help CenterGlazed Tile Metal Roofing Sheet Roll Forming Machine
Related Products
-
Corrugating Iron Cold Galvanizing Aluminium Roofing Sheet Making MachineUS$ 15,000 - 20,000MOQ: 1 Set -
Metal Sheet Roofing Glazed Steel Tile Machine,Glazed Tile Roll Forming Machine,Roll Forming MachineUS$ 15,000 - 20,000MOQ: 1 Set
-
Iron Glazed Roofing Tile Sheet Cold Rolling Forming Machine , Metal Steel Step Roof Tile Roll Forming MachineUS$ 19,000 - 30,000MOQ: 1 Set
-
Tile Forming Type Hydraulic Cutting Glazed Metal Steel Roof Tile Roll Forming Making MachineUS$ 20,000 - 40,000MOQ: 1 Set
-
Roofing Sheet Color Steel Roll Forming Manufacturer Tile Roll Forming Machine,Glazed Tile Making Machine,Corrugated FormingUS$ 15,000 - 20,000MOQ: 1 Set
Specification
Roof sheet roll forming machine
Corrugated sheet roll forming machine
Glazed metal roll forming machine
Roofing sheet roll forming machine
IBR R panel roll forming machine
Roof Roll Forming Machine Consists of
----------------------------------------------------------------------------------------------------------------------------------------
---------------------------
1. Hydraulic decoiler with Breaking device is equipped for coil processing ( manul decoiler for option)
2. Leveler
3. Hydraulic punching system
4. Hydraulic pre cutter system or post cutter system
5. Roll forming main machine
6. Run out Table or automatic stacking device
7. Mitsubishi (Japan) PLC and Touchable Screen are used for data processing and setting.
Purlin Roll Forming Machine Parameters
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------
1.Suitable material: -------------galvanized steel, colored steel
2.material thickness: -------------0.2~0.8mm (other thickness also workable)
3.Material width : -------------------as per profile
4.Material yield strength:---------up to 550mpa
5.Max Forming Speed:-----------8~25m/min
6.Roller material:------------------45# steel with heat and chrome treatment,HRC60
7.Roller driven type:---------------chain transmission or gear box transmission
8.Controller & operation:---------PLC & touchscreen,button,encoder
9.Hydraulic system pressure:--12Mpa
10.Hydraulic station power:-----3kw
11.Main motor power:------------5.5kw
12.Total power:--------------------8.5kw
13.Total weight:-------------------6~10t
Roof Sheet Roll Forming Machine Working Process-----------------------------------------------------------------------------------------------------
Hydraulic decoiler ( manul decoiler for option) -->levellering-->roll forming-->post hydraulic cutter-->auto stacker (manul run out table)
Remark: precutter for option
Roofing Tile Roll Forming Machine -----------------------------------------------------------------------------------------------------------------------------
Popular Metal Panel Profile-----------------------------------------------------------------------------------------------------------------------------------
