3 Port Optical Circulator
Description
1.The 3 port optical circulator is a compact high performance lightwave component that transmits the incoming signal from port 1 to port 2, while transmitting another incoming signal from port 2 to port 3. The component provides high isolation, low insertion loss, high extinction ratio, and excellent environment stability.
2.It is a special kind of fiber optic components, with single fiber bidirectional transmission function. This function is often combined with optical fiber grating and other reflection components used in DWDM system. Dual`way communication system, the dispersion compensation, EDFA application and OTDR measurement.
Features
1.Low insertion loss
2.Wide band high isolation
3.Low PDL
4.Compact in-line package
5.High stability and reliability
6.Epoxy free optical path
Applications
1.CATV system
2.Telecommunication network system
3.Metro/Access networks
4.Optical amplifier
5.Wavelength add / drop
6.Dispersion compensation
7.Bi-Direction communication
Specification
Parameter |
P Grade |
A Grade |
||
Configuration |
Port 1 to Port2 to Port 3 |
|||
Operation Wavelength (nm) |
1470 to 1610 |
|||
Insertion Loss (dB) |
Typical |
1.0 |
1.1 |
|
Maximum |
1.2 |
1.3 |
||
Channel Peak Isolation (dB) |
>50@1550nm |
|||
Channel Isolation (dB) |
>40(1520nm~1580nm);>32(1470nm~1610nm) |
|||
Channel Cross Talk (dB) |
>50 |
|||
Polarization Dependent Loss (dB) |
<0.20 |
|||
Polarization Mode Dispersion (ps) |
<0.1 |
|||
Return Loss (dB) |
>50 |
|||
Power Handling (mW) |
300 |
|||
Operating Temperature (°C) |
0 ~ +70 |
|||
Storage Temperature (°C) |
-40 ~ +85 |
|||
Dimensions (mm) |
Ø5.5 x L50 |
|||
Above specification are for device without connector.
Ordering Information | ||||||
3ports Optical Circulator |
Port |
Wavlength |
Grade |
Fiber Type |
Fiber Length |
In/Out Connector |
3=3 Port |
CL=C+L Band 1525~1610nm |
P=P Grade A=A Grade
|
1=Bare fiber 2=900um loose tube |
1=1m 2=2m |
0=None 1=FC/APC 2=FC/PC 3=SC/APC 4=SC/PC 5=ST 6=LC S=Specify |
|
