Industrial Tilting Jacket Cooking Kettle

Industrial Tilting Jacket Cooking Kettle thumbnail-1
Industrial Tilting Jacket Cooking Kettle photo-1
US$ 1,000 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Fillgreen
Model Number:
FG-JCG
Contact Supplier Request Quote Chat Now
Zhongshan FillGreen Packaging Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou or Shenzhen port or other ports in China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Fillgreen
Model Number FG-JCG
Type Cooking Equipment
After-sales Service Provided Engineers available to service machinery overseas

1. Description:

Jacketed cooking kettle is mainly used for food, candy, soup, meat, milk, porridge, pharmacy and chemical industry cooking and boiling. We can add the mixer, edge & bottom scraper, cover according to your need. The kettle has tilting type and stationary type. The steam jacketed kettle can be heat by gas, steam(boiler) or electric. Generally, the bigger model can choose stationary type and by steam heating.

steam jacketed kettle equiped with pressure gauge, safty valve and electric control box. Both inside and outside of th bowl are made of stainless steel, which is resistant to corrosion and in accordance with GMP standard.



2. Features:

1. Material: stainless steel 304;
2. Nominal capacity: 50-1000L;
3. Large heating area, evenly heating;
4. High thermal efficiency, short boiling time
5. Heating temperature is easy to control;
6. Nice appearance;
7. Easy to install and operate;
8. Safe and reliable.





3.  Technical parameter:

Model FG-50 FG-100 FG-200 FG-300 FG-400 FG-500 FG-600 FG-800 FG-1000
Capacity 50L 100L 200L 300L 400L 500L 600L 800L 1000L
Open Diameter(mm) 560 700 800 900 1000 1100 1200 1300 1400
Depth 400 450 530 630 680 730 780 830 900
Heating area(m2) 0.40 0.58 1.12 1.42 1.75 2 2.3 3.2 3.9
Heaing pipe power 1kw*3 3kw*3 5kw*3 6kw*3 6kw*3 8kw*3 8kw*3 9kw*3 10kw*3
Conduction oil 25L 36L 45L 60L 70L 80L 100L 200L 250L
Working pressure Equal and less than 0.09Mpa
Mixing speed 36r/min
Mixer power 0.3kw 0.55 0.75 1.1 1.1 1.5 1.5 2.2 2.2





4. Packaging & shipping:

Packaging: international standard exporting wooden case;
Shipping:by sea





5. Samples machine pictures only for your reference:



Industrial tilting jacket cooking kettleIndustrial tilting jacket cooking kettleIndustrial tilting jacket cooking kettleIndustrial tilting jacket cooking kettle

Industrial tilting jacket cooking kettle
Industrial tilting jacket cooking kettle

Industrial tilting jacket cooking kettle
