Conventional Rawedge Cogged V-Belts 3VX 5VXApplications: Large sized pumps, crushers, dynamos, tooling machines, freezer
Conventional Rawedge Cogged V-Belts 3VX 5VX
Narrow v belt for automobile
Narrow Wrapped V-belt (MAXSTAR WEDGE Belt)
Characteristics:
This belt has double power transmission capacity of the Standard V-belts
due to the effect of the wedge.It features maximum 40 m/sec.
highspeed transmission, and an energysaving, compact design.
A banded type that can prevent turnover and
ensures stable running is also available.
narrow v belt
Section |
Top width (mm) |
Thickness (mm) |
Length range (mm) |
Angle |
RA |
13.6 |
10 |
1200~5000 |
40° |
RB |
17 |
13 |
1200~10000 |
40° |
RC |
22.4 |
16 |
1800~10000 |
40° |
RD |
32.8 |
21.5 |
4500~15000 |
40° |
R3V |
9.7 |
9.7 |
1200~5000 |
40° |
R5V |
15.8 |
15.8 |
1500~10000 |
40° |
R8V |
25.4 |
25.4 |
2000~1000 |
40° |
item |
top width |
pitch width |
height |
length range(mm) |
3V(9N) |
9.7 |
10.3 |
9.7 |
1200-5000 |
5V(15N) |
15.7 |
17.5 |
15.7 |
1500-10000 |
8V(25N) |
25.4 |
28.6 |
25.4 |
2000-10000 |
SPZ |
10.5 |
/ |
10.0 |
1200-5000 |
SPA |
13.6 |
/ |
12.3 |
1200-5000 |
SPB |
17.0 |
/ |
16.5 |
1500-10000 |
SPC |
22.0 |
/ |
21.0 |
3000-12500 |
Applications: Large sized pumps, crushers, dynamos, tooling machines, freezers
natural rubber Narrow Wrapped V-belt
Belt types:
1. MAXSTAR WEDGE3V, 5V, 8V (SPA, SPB, SPC,SPZ)
2. Multi MAXSTAR (Banded type)R3V, R5V, R8V
narrow v belt
narrow v belt type SPA
Our factory
