Specifications
v belt1.very commonly used for power transmission.
2.a wide range of types
3. banded V-belts
v belt
Characteristics:
1.This belt is very commonly used for power transmission.
2.We supply a wide range of types including heat resistance,oil resistance and flexible types.
3.We also supply banded V-belts, a banded versionthat prevents vibration,
turnover and ensures stable running.
Applications:
A wide range of machinery from light duty power transmission for OA
and household electric appliances to heavy duty power transmission
such as printing machines, machine tool and crushers.
v belt
Production Type |
Top Width |
Pitch Width |
Height |
Angle |
Length range |
O(Z) |
10 |
8.5 |
6 |
40° |
450mm-2500mm |
A |
13 |
11.0 |
8 |
40° |
500mm-3550 |
B |
17 |
14.0 |
11 |
40° |
600mm-6400mm |
C |
22 |
19.0 |
14 |
40° |
1180mm-1200mm |
D |
32 |
27.0 |
19 |
40° |
2200mm-1400mm |
E |
38 |
32.0 |
23 |
40° |
3000mm-16000mm |
Belt types:
1. Standard Type & Red Type(K), M, A, B, C, D, E (Z)
2. Banded V-belts (multi-type)RA, RB, RC, RD, RE
3. Bare Back Type (prevents generation of rubber powder)M, A, B, C
4. AG Series for Agricultural MachineryA, B, C, D
v belt
About our company
Weishi Hongli Rubber Co., Ltd. is an export-oriented production enterprise. Our factory is located in Daying
Industrial Development District of Weishi County.Henan
Province,which is 15km from Lannan highway in the east,30km
from Zhengzhou International Airport in the west. Our main
products include stiff cord v-belt, color v-belt, wrapped v-belt,
banded belts,agricultural v-belt, conveyor belt and oil seal.
With advanced V-belt production line in China and
the adoption of international standard, our factory has passed
the authentication of ISO9001 quality management system.
With a good reputation among customers, Our company
manufactures with the trade mark of "MOLI" and"double lion"
rubber products; have been exported to more than 10 countries
and regions.
