High Quality factory directly low differential pressure sensor

High accuracy
0.2% accuracy for all calibrated spans is the standard feature for pressure transmitter covering 40 to 3000kPa, 0.1% accuracy as option. The compositive monocrystalline piezoresistive sensor assures this accuracy for all elevated or suppressed calibration ranges without additional adjustment.

Minimum environmental influence
The Advanced Cell design, which protects the pressure sensor against changes in temperature, static pressure, and overpressure substantially reduces total measurement error in actual field applications.

Span, range
Working pressure Span (kPa abs) Range (kPa) Over range
Type (kPa abs) Min. Max. LRL URL MPa
SKA 01 0~40 2 40 0 40 0.12
SKA 02 0~250 2.5 250 0 250 0.75
SKA 04 0~3000 30 3000 0 3000 9 Note: LRL= Lower Range Limit; URL= Upper Range Limit.
To minimize environmental influence, span should be greater than 1/40 of the max. span in most applications.

Process temperature
(-40~85)℃
(-20~85)℃(for explosion proof units)

Performance Specifications for Linear Output
(Zero-based calibrated ranges, reference conditions, silicone oil fill, 316L SST isolating diaphragms and 4 to 20mA analog output in linear mode.)

Accuracy rating (including linearity, hysteresis, and repeatability)
Standard:For spans greater than 1/10 of URL: ±0.2% of span Option(21st digit: H,Not available for 40kPa abs and 250kPa abs):
For spans greater than 1/10 of URL: ±0.1% of span
Temperature effect
Effect per 28℃ change between the limits of -40℃ and +85℃
Over range effect
Zero shift: ±0.2% of URL for any over range to maximum limit
Stability
±0.2% of upper range limit (URL) for 10 years.
Mounting position effect
Zero shift: less than 0.1kPa for a 10° tilt in any place .No effect on span. This error can be corrected by adjusting zero.

Physical Specifications
Process-wetted parts material
Material code
(7th digit in "Ordering Code") Process cover Process-wetted body
Diaphragm Wetted sensor body
V CF8M 316L SST 316 SST
M CF8M Hastelloy-C 316 SST
J CF8M 316L SST + Au coating 316 SST
H CF8M Hastelloy-C Hastelloy-C
P CF8M 316L SST+ PTFE coating 316L SST
T CF8M Tantalum 316 SST
Non-wetted parts material
Electronics housing
Low copper die-cast aluminum alloy finished with polyester coating (silver), or CF8M, as specified.
Electronics housing cover
Low copper die-cast aluminum alloy finished with polyester coating (atrovirens), or CF8M, as specified.
Environmental protection
IEC IP67
Mass (weight)
Transmitter approximately 3.1 kg without options
Electrical connections
½-14NPT or M20×1.5 conduit, as specified.
External terminal
M4 screw
Process connections
¼-18NPT
Mounting
On 50A(2B) pipe using mounting bracket, direct wall mounting or direct process mounting.
Transmission unit position
The transmission unit can be turned at 90° or 180°in the clockwise or counterclockwise direction.
