Good Reputation Factory Directly High Precision Pressure Transmitter

Name: Good Reputation Factory Directly High Precision Pressure Transmitter
Brand: SUPCON
SKU: 126057085

Good Reputation Factory Directly High Precision Pressure Transmitter thumbnail-1

Good Reputation Factory Directly High Precision Pressure Transmitter photo-1

US$ 500 - 1,000 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

SUPCON

Model Number:

SKC Differential Pressure/Flow/Transmitter

Contact Supplier Request Quote Chat Now

Zhejiang Supcon Instrument Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

ShangHai NingBo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name SUPCON

Model Number SKC Differential Pressure/Flow/Transmitter

Features
1	High accuracy 0.065% accuracy for all calibrated spans is the standard feature for pressure transmitter covering 0.1 to 3000kPa, up to 0.04% accuracy as option. The compositive monocrystalline piezoresistive sensor assures this accuracy for all elevated or suppressed calibration ranges without additional adjustment.
2	Minimum environmental influence The Advanced Cell design, which protects the pressure sensor against changes in temperature, static pressure, and overpressure substantially reduces total measurement error in actual field applications.
3	Application flexibility Various options that render the CXT suitable for almost any process applications include: –Full range of hazardous area approvals – Built-in RFI filter and lightning arrester – 5-digit LCD meter with engineering unit – Stainless steel electronics housing – Wide selection of anticorrosion materials

Specifications
1	Span, range Static pressure Span (kPa) Range (kPa) Type (MPa) Min. Max. LRL URL SKC 22 -0.1~7 0.2 6 -6 +6 SKC 33 -0.1~16 0.4 40 -40 +40 SKC 35 -0.1~16 2.5 250 -250 +250 SKC 36 -0.1~16 8 800 -800 +800 SKC 38 -0.1~16 30 3000 -3000 +3000 Note: LRL= Lower Range Limit; URL= Upper Range Limit. To minimize environmental influence, span should be greater than 1/40 of the max. span in most applications.
2	Process temperature, Lower range limit Fill Fluid 13th digit code Process temperature Lower range limit Silicone oil Y, G (-40~120)℃ 2.7kPa abs Fluorinated oil W, A, D (-20~80)℃ Atmospheric pressure Note: For explosion proof units, process temperature is (-20~120)℃.
3	Performance Specifications for Linear Output (Zero-based calibrated ranges, reference conditions, silicone oil fill, 316L SST isolating diaphragms and 4 to 20mA analog output in linear mode.) Accuracy rating (including linearity, hysteresis, and repeatability) For 6th digit code 3, 5, 6 and 8: For spans greater than 1/10 of URL: ±0.065% of span or ±0.04% of span (21st digit: H) For spans below 1/10 of URL: of span For 6th digit code 2: For spans greater than 1/10 of URL: ±0.1% of span For spans below 1/10 of URL: of span Stability ±0.1% of upper range limit (URL) for 10 years. Temperature effect Effect per 28℃ change between the limits of -40℃ and +85℃ For 6th digit code 2: For 6th digit code 3, 5, 6 and 8: Static pressure effect For 6th digit code 2: ±[0.07%Span+0.05%URL]/3.4MPa For 6th digit code 3, 5, 6 and 8: ±[0.1%Span+0.025%URL]/6.9MPa Mounting position effect Zero shift: less than 0.12kPa for a 10° tilt in any place (0.24kPa for 13th digit code "W","D","A").No effect on span. This error can be corrected by adjusting zero.
4	Performance Specifications for Square Root Output Accuracy rating For 6th digit code 2: Output Accuracy (50~100)% ±0.1% (20~50)% ±0.25% (10~20)% ±0.5% For 6th digit code 3, 5, 6 and 8: Output Over 10% URL (50~100)% ±0.065% (20~50)% ±0.163% (10~20)% ±0.325%
5	Physical Specifications Process-wetted parts material Material code (7th digit in "Ordering Code") Process cover Process-wetted body Static pressure (MPa) Diaphragm Wetted sensor body 0.2 10 16 40 V CF8M 316L SST 316 SST √ √ √ √ W CF8M Hastelloy-C 316 SST √ √ √ √ J CF8M 316L SST + Au coating 316 SST √ √ √ √ H CF8M Hastelloy-C Hastelloy-C √ √ √ √ P CF8M 316L SST+ PTFE coating 316L SST - - √ √ T CF8M Tantalum Tantalum - - √ √ Remarks: Availability of above material design depends on ranges. Refer to "Ordering Code". Non-wetted parts material Electronics housing Low copper die-cast aluminum alloy finished with polyester coating (silver), or CF8M, as specified. Electronics housing cover Low copper die-cast aluminum alloy finished with polyester coating (atrovirens), or CF8M, as specified. Environmental protection IEC IP67 Mass (weight) Transmitter approximately 3.1 to 3.6kg without options Electrical connections ½-14NPT or M20×1.5 conduit, as specified. External terminal M4 screw Process connections ¼-18NPT Mounting On 50A(2B) pipe using mounting bracket, direct wall mounting or direct process mounting. Transmission unit position The transmission unit can be turned at 90° or 180°in the clockwise or counterclockwise direction.

Item Name	SKCEN Differential Pressure (Flow) Transmitter
Material	Metal
Size	L121W94H190cm
Color	silver and atrovirens
Process	Casting,Stamping,Polishing,Filling Silicon Oil, Painting, Assembly, Calibrating, Packaging
Custom Desigh	Welcome
Service	OEM&ODM
MOQ	1pcs
Sample	Available
Sample Cost,The cost will be returned after placing an order	USD600
Sample Lead Time	7-15 Days
Payment Terms	T/T, LC at sight,west union,paypal
Packing	carton package with protection material
Production Time	15-30 Days
Delivery Port	Ningbo or Shanghai

Q: Are you a manufacture or a trading company?

A: We are a 20-year-manufacturer engaged in the field of cleaning products, and we have got the permit of import and export as well.

Q: Where is your factory located? How can I visit there?

A: Our factory is located in Hangzhou, China. 25 Minutes by car far away from Xiaoshan Airport.

Q: How can I get the Good Reputation factory directly high precision pressure transmitter samples? What's the lead time?

A: Samples could be sent within one week, the lead time is 35-45 days..

Q: Do you provide Good Reputation factory directly high precision pressure transmitter ODM/OEM service?

A: OEM/ODM is welcome, there are 25 persons in our R&D team, and customized colours is optional. From the concept to finished goods, we do all (design, prototype reviewing, tooling and production) in the factory.
