Help CenterSB3041 Single Channel Isolated Barrier
Related Products
-
HD5500 DIN Rail Signal Isolator Swith InterfaceNegotiableMOQ: 1 Case -
SB3000 Signal Isolators, Isolated Barrier, Isolator SwitchNegotiableMOQ: 1 Case
-
SB3000-Ex Series Isolated BarrierUS$ 45 - 60MOQ: 1 Case
-
SUPCON Super Thin Signal Isolator HD5500 SeriesNegotiableMOQ: 1 Case
-
SB3016/OC NPN Transistor Open Collector Output Signal IsolatorsUS$ 130 - 131MOQ: 20 Pieces
The SB3041 single channel isolated barrier
Dimension
114.5mm×99.0mm×17.5mm
Number of channels
Two
Input and output signal range
4 to 20mA
Field side circuit load resistance
Max 550Ω (16V at 20mA)
Input and output circuit ripple
<40μA peak-to-peak
Transfer accuracy at 20°C
Better than 16μA
Temperature drifts
<1μA/°C
Response time
Settles to within 10% of final value after typically 500μs
LED indicators
Green: power indication
Power supply
Voltage: (20~35)VDC Current: (with two 20mA signals) 75mA at 20V 65mA at 24V 50mA at 35V Power: 1.56W typical at 24V with two 20mA signals
Isolation
250V AC/DC between control station and filed circuits
| Item Name | SB3041 isolated barrier | |||||||||
| Material | Plastics | |||||||||
| Size | 114.5mm×99.0mm×17.5mm | |||||||||
| Color | Green | |||||||||
| Process |
Casting,Stamping,Polishing,Filling Silicon Oil, Painting,Assembly,Calibrating,Packaging |
|||||||||
| Custom Desigh | Welcome | |||||||||
| Service | OEM&ODM | |||||||||
| MOQ | 20 pcs | |||||||||
| Sample | Available | |||||||||
|
Sample Cost,The cost will be returned after placing an order |
USD130 | |||||||||
| Sample Lead Time | 7-15 Days | |||||||||
| Payment Terms | T/T, LC at sight,west union,paypal | |||||||||
| Packing | carton package with protection material | |||||||||
| Production Time | 15-30 Days | |||||||||
| Delivery Port | Ningbo or Shanghai | |||||||||
