Supcon range 0~50v votage input signal isolator SB3047
- 5000 Case / Cases per Month
- Ningbo Shanghai
- T/T
You May Like
-
SB3046 analog output with HART Supcon isolated barrier
-
SB3045 analog output Supcon isolated barrier signal isolator
-
SB3044 two channel analog input Supcon isolated barrier
-
SUPCON 4~20mA analog signal separation isolator
-
SB3042 single channel isolated barrier with hart communication
-
SB3041 single channel isolated barrier
Product Details
Place of Origin | Zhejiang, China | Brand Name | SUPCON | |
Model Number | SB3047 |
20 Pcs/Ctn for isolated barrier, Packing Size: 320*240*250 mm
Product Description
The SB3047 accepts a signal 0/50V max from the field, and converts to 4/20mA or 1/5V signal to drive a load in control-station side. The signal range can be customized such as 0/10V, 0/40V etc. within the max range 0/50V.
Dimension
114.5mm×99.0mm×17.5mm
Number of channels
1
Input signal range
0 to 50V
Input signal span
10 to 50V
Output signal range
4 to 20mA or 1 to 5V Note: Clear indication should be given in ordering code when 1 to 5V is needed,
Control-station side circuit load resistance
Max 550Ω
Output circuit ripple
<40μA peak-to-peak
Transfer accuracy at 20°C
Better than 16μA
Temperature drifts
<1.6μA/°C <0.4mV/°C
Response time
Settles to within 10% of final value after typically 60ms
LED indicators
One provided for power indication
Power supply
Voltage: 24VDC±10% Current: 80mA typical at 24V with 20mA signal Power: 1.92W typical at 24V with 20mA signal
Isolation
250V AC/DC between control station and filed circuits
Item Name | SB3047 range 0~50v votage input Supcon signal isolator | |||||||||
Material | Plastics | |||||||||
Size | 114.5mm×99.0mm×17.5mm | |||||||||
Color | Green | |||||||||
Process | Casting,Stamping,Polishing,Filling Silicon Oil, Painting,Assembly,Calibrating,Packaging | |||||||||
Custom Desigh | Welcome | |||||||||
Service | OEM&ODM | |||||||||
MOQ | 20 pcs | |||||||||
Sample | Available | |||||||||
Sample Cost,The cost will be returned after placing an order | USD50~80 | |||||||||
Sample Lead Time | 7-15 Days | |||||||||
Payment Terms | T/T, LC at sight,west union,paypal | |||||||||
Packing | carton package with protection material | |||||||||
Production Time | 15-30 Days | |||||||||
Delivery Port | Ningbo or Shanghai |
