mV, THC or RTD input
Dimension
114.5mm×99.0mm×17.5mm
Number of channels
1
Signal source
Millivolt Types J, K, T, E, R, S, B or N THCs to IEC584 3-wire PT100 or Cu50 RTDs to BS1904/DIN 43760
Input signal range
-75 to +75mV, or 0 to 450Ω
Input signal span
3 to 150mV, or 10 to 450Ω
Cold junction compensation
Automatic Error: ±1.0℃
Common mode rejection
120dB for 250V at 50Hz/60Hz
Series mode rejection
40dB for 50Hz/60Hz
Calibration accuracy (at 20℃)
(Includes hysteresis, non-linearity and repeatability) Inputs: mV/THC: ±15μV or±0.05% of input value (whichever is greater) RTD: ±80mΩ Output: ±11μA
Temperature drifts (typical)
Inputs: mV/THC: ±0.003% of input value/℃ RTD: ±7mΩ/℃ Output: ±1.0μA/℃
Output range
4 to 20mA or 1 to 5V Note: Clear indication should be given in ordering code when 1 to 5V is needed. Control-station side circuit load resistance
0 to 550Ω
LED indicators
One provided for power indication
Power supply
Voltage: (20~35)VDC Current: (with 20mA signal) 44mA at 20V 40mA at 24V 32mA at 35V Power: 1W typical at 24V with 20mA signal
Isolation
250V AC/DC between control station and filed circuits
| Item Name | SB3073 TEMPERATURE CONVERTER | |||||||||
| Material | Plastics | |||||||||
| Size | 114.5mm×99.0mm×17.5mm | |||||||||
| Color | Green | |||||||||
| Process |
Casting,Stamping,Polishing,Filling Silicon Oil, Painting,Assembly,Calibrating,Packaging |
|||||||||
| Custom Desigh | Welcome | |||||||||
| Service | OEM&ODM | |||||||||
| MOQ | 20 pcs | |||||||||
| Sample | Available | |||||||||
|
Sample Cost,The cost will be returned after placing an order |
USD130 | |||||||||
| Sample Lead Time | 7-15 Days | |||||||||
| Payment Terms | T/T, LC at sight,west union,paypal | |||||||||
| Packing | carton package with protection material | |||||||||
| Production Time | 15-30 Days | |||||||||
| Delivery Port | Ningbo or Shanghai | |||||||||
