Help CenterHD5542
US$ 150 - 151
MOQ: 20 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
SUPCON
Model Number:
HD5542
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SUPCON SB3041 Isolated BarrierUS$ 135 - 136MOQ: 20 Pieces -
SUPCON HD5544US$ 150 - 151MOQ: 20 Pieces
-
SUPCON HD5543 REPEATER POWER SUPPLY Isolated BarrierUS$ 150 - 151MOQ: 20 Pieces
-
SUPCON SB3047 VOLTAGE CONVERTER Isolated BarrierUS$ 135 - 136MOQ: 20 Pieces
-
SUPCON SB3073US$ 135 - 136MOQ: 20 Pieces
Place of Origin
Zhejiang, China
Brand Name
SUPCON
Model Number
HD5542
| HD5542 REPEATER POWER SUPPLY | ||||||||||||||
| 1 |
The HD5542 provides a fully floating dc supply for energizing a conventional 2- or 3-wire 4/20mA transmitter located in a hazardous area and repeats the current in another floating circuit to drive a safe-area load. For smart 2-wire transmitters, the HD5542 allows bi-directional HART communications signals superimposed on the 4/20mA signal. |
|||||||||||||
| 2 | Number of channels 1 Location of transmitters Zone0, IIC, T4-T6 hazardous areaDiv 1, Group A, hazardous location Safe-area output Signal range: 4 to 20mA Under/over-range: 0 to 24mA Safe-area load: 0 to 360Ω @24mA 0 to 450Ω @20mA Safe-area circuit output resistance: > 1MΩ Hazardous-area input Signal range: 0 to 24mA Transmitter voltage: 15V at 20mA Transfer accuracy Better than 15μA Temperature drift Better than 0.8μA/℃ |
|||||||||||||
| 3 | Response time Settles to within 10% of final value within 750μs (In case of 250Ω typical safe-area load) Communications supported Bi-directional HART communications Power supply (20~35)VDC Max current consumption 51mA at 24VDC Isolation 250V AC/DC between safe and hazardous area circuits NEPSI max approval parameters Terminals 3-1(4) or 3-1(4)-2: Uo=28V, Io=93mA, Co=0.083μF, Lo=4.2mH, Po=660mW LED indicators PWR:green for power on indication LFD:red for open circuit or output overload indication |
|||||||||||||
| Item Name | HD5542 REPEATER POWER SUPPLY | |||||||||
| Material | Plastics | |||||||||
| Size | 127.5mm×118.9mm×12.7mm | |||||||||
| Color | Gray/Blue | |||||||||
| Process |
Casting,Stamping,Polishing,Filling Silicon Oil, Painting,Assembly,Calibrating,Packaging |
|||||||||
| Custom Desigh | Welcome | |||||||||
| Service | OEM&ODM | |||||||||
| MOQ | 20 pcs | |||||||||
| Sample | Available | |||||||||
|
Sample Cost,The cost will be returned after placing an order |
USD130 | |||||||||
| Sample Lead Time | 7-15 Days | |||||||||
| Payment Terms | T/T, LC at sight,west union,paypal | |||||||||
| Packing | carton package with protection material | |||||||||
| Production Time | 15-30 Days | |||||||||
| Delivery Port | Ningbo or Shanghai | |||||||||
