Help CenterSUPCON Single Anolog Input Signal Isolator SB3041EX 4~20mA
Related Products
Dimension
114.5mm×99.0mm×17.5mm
Number of Channels
1
Voltage available for transmitter and lines
15V minimum at 20mA Note: maximum open-circuit voltage is 28V.
Input and output signal range
4 to 20mA or 1 to 5V Note: Clear indication should be given in ordering code when 1 to 5V is needed.
Control-station side circuit load resistance
0 to 550Ω
Output circuit ripple
<40μA peak-to-peak
Transfer accuracy at 20°C
Better than 16μA
Temperature drifts
<1μA/°C
Response time
Settles to within 10% of final value after typically 60ms
LED indicators
One provided for power indication
Power supply
Voltage: (20~35)VDC Current: (with 20mA transducer load) 67mA at 20V 60mA at 24V 44mA at LED indicators
One provided for power indication
Power supply
Voltage: (20~35)VDC Current: (with 20mA transducer load) 67mA at 20V 60mA at 24V 44mA at 35V Power: 1.44W typical at 24V with 20mA signal Isolation
250V AC/DC between control station and filed circuits
| Item Name | SUPCON single anolog input signal isolator SB3041EX 4~20mA | |||||||||
| Material | Plastics | |||||||||
| Size | 114.5mm×99.0mm×17.5mm | |||||||||
| Color | Green | |||||||||
| Process |
Casting,Stamping,Polishing,Filling Silicon Oil, Painting,Assembly,Calibrating,Packaging |
|||||||||
| Custom Desigh | Welcome | |||||||||
| Service | OEM&ODM | |||||||||
| MOQ | 20 pcs | |||||||||
| Sample | Available | |||||||||
|
Sample Cost,The cost will be returned after placing an order |
USD50~60 | |||||||||
| Sample Lead Time | 7-15 Days | |||||||||
| Payment Terms | T/T, LC at sight,west union,paypal | |||||||||
| Packing | carton package with protection material | |||||||||
| Production Time | 15-30 Days | |||||||||
| Delivery Port | Ningbo or Shanghai | |||||||||
