Knitted Fabric Bursting Strength Tester Price, Mullen Burst Tester for Bursting Strength

US$ 1,250 - 1,390 MOQ: 1 Unit

Key Specifications

Place of Origin:

Gujarat, India

Brand Name:

EIE

Model Number:

PTBT-101D

Eie Instruments Private Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Nava Sheva Maharasta

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Gujarat, India

Brand Name EIE

Model Number PTBT-101D

Power Electronic

Usage Strength Testing Machine

Complies with following International Standards
ISO 2758, 2559, 3303, 3689, BS 3424, 3137, ASTM 3786, ASTM D 774

Salient Features

Proven and reliable performance
Scientifically calibrated through our in-house calibration laboratory
Sturdy in construction
Low power consumption
Noise-less functioning
Correctly matched motor gives constant pumping rate, eliminating manual error as per ASTM, BS and ISO Standard requirements.
Equipped with Microprocessor Based LCD Display Controller
Suitable to test sample up to 25kg/cm2
Displays Resolution of 0.1 kg/cm²
Digital Indication for accurate reading
Controller having Facility to Adjust Unit Selection viz. Kg/cm²,Bar and PSI
Stores data up to last ten readings & gives Average Value, Max. Value & Min. Value of the Tests.
Facility to perform batch testing up to 10 test and record data in memory.
Quick, Easy, Accurate & User Friendly Operation
All replaceable parts readily available

Technical Specifications

Instrument Body: Fabricated from Mild Steel Material
Paint : Powder coating in attractive shades
Body size : 22” x 14” x 21” (L x W x H)
Test Fluid : Glycerin or EP 140 Gear Oi
Capacity of Test Fluid tank : 250 ml
Rate of Fluid Displacement : 95 ± 5 ml / Minute
Opening of upper clamp : 31.5 mm
Opening of lower clamp : 30.5 mm
Electric Motor : Reputed make stepper motor to yield constant rate of pumping
Pressure transducer : Honeywell of Danfoss make
Controller : Microprocessor based Digital Programmable controller
Display : LCD Display with back light indication
Maximum Capacity : 25 Kg/cm2
Pressure Resolution : 0.1 Kg/cm2
Unit selections : Yes – Kg/cm2, Bar, PSI
Data storage : Up to last 10 readings and further expandable (See optional accessories)
Power supply : 220 Volts, 50 Hz, Single Phase, AC Supply
