High Speed Rotary Water Filler for Multi Bottle Size (GZ36000)

High Speed Rotary Water Filler for Multi Bottle Size (GZ36000) photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
Huangpu
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Beverage
Packaging Type Bottles
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 380V
Power 11KW
Place of Origin Guangdong, China
Brand Name VANTA
Model Number WSD-GZ36000
Dimension(L*W*H) 7800X5500X3250
Weight 13T
Certification CE
After-sales Service Provided Engineers available to service machinery overseas



Product information

High Speed Rotary Water Filler for Multi Bottle Size (GZ36000) 1.    Description

Vanta's 3-in-1 filling machine is in combination with rinsing, filling and capping technology. It is innovated and designed in the requirement of still pure water and mineral water and  based on introducing and fusing advanced technologies from Germany and Italy.


2.    Datasheet

Water filling machine modelWSD-GZ36000
Capacity (BPH)36000
Filling volume (L)0.35-2
Rinser-filler-capper quantity50-50-15
Bottle size (mm)Φ50-Φ90
H 150-310
Filling accuracy (%)±2
Pneumatic pressure (mpa)0.5
Air consumption (L/min)1000
Rated voltage (V)380
Motor power (kw)11
Rinsing water consumption ( /h)5
Filling water consumption ( /h)18
Dimensions (LXWXH mm)7800X5500X3250
Weight (kg)13000





3. Competitive advantages
3.1  It adopts human-machine interface control technology.
3.2  Main components are imported from international famous brand.
3.3  The suspension bottle neck catcher structure allows the easy change of bottle type.
3.4  Spring type rinsing catcher can wash both inside and outside of the bottle.
3.5  The magnetic torsion type screw capper ensures the tightness of the cap and avoids bottle damage.
3.6  Uses rotary cap unscramble to ensure no damage or noise and photoelectric sensor to detect missing cap.
3.7  Safety protection device ensures the safety of operator and machine.
3.8  High quality air filter ensures the working airflow  conforms to sanitation criteria.



4. Product:

High Speed Rotary Water Filler for Multi Bottle Size (GZ36000)





Company Profile

High Speed Rotary Water Filler for Multi Bottle Size (GZ36000)



Company Advantages





Packaging

High Speed Rotary Water Filler for Multi Bottle Size (GZ36000)



After-Sales Service

High Speed Rotary Water Filler for Multi Bottle Size (GZ36000)



Our Customer

High Speed Rotary Water Filler for Multi Bottle Size (GZ36000)



Exhibition

High Speed Rotary Water Filler for Multi Bottle Size (GZ36000)
