Vertical Automatic Flat Press Double Glazing Machine/Double Glass Making Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Machine Type:
Insulating Glass Production Line
Production Capacity:
1200 pieces/day
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Aluminum Profile Tenon Milling EquipmentNegotiableMOQ: 1 Set -
Aluminum Hydraulic Crimping Machine/Aluminum Corner Joint MachineNegotiableMOQ: 1 Set
-
Aluminum Automatic End Milling Machine/Tenon MachineNegotiableMOQ: 1 Set
-
Aluminum Automatic Tenon Machine /Mortise and Tenon MachineNegotiableMOQ: 1 Set
-
Aluminum Automatic Mortise and Tenon Machine/tenon MachineNegotiableMOQ: 1 Set
Condition
New
Machine Type
Insulating Glass Production Line
Production Capacity
1200 pieces/day
Place of Origin
China
Brand Name
PARKER
Model Number
IGV22-S
Voltage
380V
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.Insulating Glass Production Line2.CNC Double Glass Production Line
3.CE
4.Low-e Glass
5.Coated Glass
Vertical Automatic Flat Press Double Glazing Machine/Insulating Glass Produce Line
Product Description
- Double glass making machine
- This new-developed production line is ideal equipment in IGU producing with its wide processing capacity, high efficiency and super automation level, humanized design and nice looking.
- The rack is welded by rectangular pipe after several times analysis and test, painted after pickling and phosphate treatment. The backboard in transmission adopt laser-bended high-strength carbon steel sheet for high strength and precision. The washing and drying section adopt stainless steel against rusting.
- 6°incline of the vertical line reveal the advanced technology. The system circuits controlled by 24V voltage and shock protection treatment in transmission section make it easy to modify and operate.
- Low-voltage imported electrical fittings and sensors are adopted. High automation is guaranteed by PLC’s overall control of the whole processing. The original touch screen displays in sync with the simultaneous action and malfunction of the production line, meanwhile easy to learn and operate.
- Multi- frequency converting in several section and multi-speed operation make it possible to process stepped glass sheets.
- Imported pneumatic fittings have long service life and are easy to maintain. The pneumatic system can realize automatic water filtering, releasing and lubricating.
- Three-axis servo control system can finish the manufacturing of various glass units including stepped glass, overlarge glass, shaped glass, filmed glass, Low-E glass, triple glazing so on and so forth.
Parameter:
|
380V(3P+N) 50Hz |
|
23.7KW |
|
0.5-0.8Mpa |
|
160L/min |
|
0-12m/min |
|
40m/min |
|
2200mm x 3000mm |
|
250mm x 480mm |
|
12-60mm |
|
21000mm x 2100mm x 3300mm |
|
4800Kg |
Company Information
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2003
Factory Size
5,000-10,000 square meters
Total Employees
301 - 500 People
