Features:
LJZ-CNC-500X4200 is used for cutting of alu-alloy and wall profile. The imported special hard-metal saw features the high precision and efficiency for cutting alu-alloy doors and windows. And the cutting precision has reached the advanced level in the world.
The hi-precision main shaft makes the saw stable and the surface smooth. The gas-liquid damping cylinder realizes smooth feeding and steady moving. The automatically opening and closing protecting cover makes the operation safe and easy.
The moving heads adopt imported linear bearing motion pair, and they features high precision. The moving feeder can efficiently locate the profile, and making the clamping easy and reliable. With the large saws and long structures, the saw has large cutting range.
CNC system is put in, it can make the cutting much more precise (precision 0.01mm), and the operating more visualized.
380V 50HZ
Power:
4.4KW
Air pressure:
0.5-0.8MPa
Air consumption:
200L/min
Blade specification:
Φ500XΦ30X4.4 Z=120(standard size)
Cutter moving speed:
0-2m/min
Cutting length:
Max4000mm Min200mm
Cutting width:
Max.135mm
Cutting height:
Max.300mm
Cutting angle:
45° 90°
Repeat locating length error:
±0.2mm
Angle error
±4′
Surface plainness:
±0.1mm
Surface harshness:
Ra12.5μm
Overall dimension:
5500mmX1750mmX1990mm
Founded in 2003, Parker Machinery Co., Ltd has developed an assembly line for door, window, curtain wall and insulating glass equipment. With over ten years' production experience, Parker has become a leading manufacturer of window door machinery in China. The operation of high precision, advancement and specialty ensure that we are able to supply high-quality window and door equipment for customers.
During the past few years, Parker has made great progress and has become well known and outstanding in domestic fairs for window door machinery. With advanced technological equipment, tremendous technical strength and reliable product quality, our window and door equipment has been well received by customers from Russian, Kazakhstan, Vietnam, Iran, etc. We have a perfect sales network and complete service system in China. We are also taking a leading role in setting branch companies abroad.
Packaging & Shipping
Plastic package,Wooden pallet or as required.
