samsung video wall,samsung seamless video wall
samsung video wall,samsung seamless video wall is designed for large-scale combinatorial splicing display system of professional products, The special project LCD monitor of current ultra narrow edge. Engineering structure design of i-Panel module, digital network technology and strong expansibility, make product function powerful, quality excellence.
samsung video wall,samsung seamless video wall with high contrast ration(4000:1), high reoslution(1920X1080), high brightness(700cd/m2) etc,
Static and dynamic picture can guarantee precise, delicate rendering.
Built-in splicing function, max achievable 15x15 splicing by the display built-in splicing function.,max 690 inches big picture.
samsung video wall,samsung seamless video wall supports analog, digital video and computer signals, Supports various proportions display, the highest resolution up to 1920x1080.
samsung video wall,samsung seamless video wall adopt special project LCD panel, high temperature resistant, Low power consumption, small heat, service life more than 60,000 hours. can continuous work for 7x24 hours.
| Specification: | ||
| LCD panel | Model number | IP46UH |
| Panel size | 46" | |
| Aspect ration | 16:9 | |
| Backlight | LED backlight | |
| Resolution | 1920x1080 | |
| Panel type | SPVA | |
| Active area | 1018*573mm | |
| View angle | 89/89/89/89 | |
| Contrast ration | 4000:1 | |
| Brightness | 700cd/m2 | |
| Respone time | <8ms | |
| Display color | 10Bit,1073.7M | |
| Pixel pitch | 0.176(H) x 0.53(W)mm | |
| Max. resolution | 1920x1080 | |
| Compatible resolution | 1920x1080;1680x1050;1600x1200;1440x1050;1360x768; 1280x1024;1280x768; 1024x768;832x624;800x600;720x400; 600x480; | |
|
Basic spec |
input interface | 1xVGA |
| 1xDVI | ||
| 1xHDMI | ||
| 2xVideo/Audio | ||
| 1xRJ45(be used in RS23S IN) | ||
| 1x Professional debugging | ||
| Output interface | 2xRJ45(be used in RS232 OUT) | |
| Power supply | AC Input 100~240V(+/-10%)/50-60Hz | |
| Power | ≤240W | |
| Standby power | ≤2W | |
| Operation mode | key control, infrared control, remote control | |
| Bus control | I2C | |
| Video format | PAL. NTSC | |
| Work temperature | 00C~500C | |
| Work humidity | 10%~90% | |
| Storage temperature | -200C~600C | |
| Storage humidity | 0%~90% | |
| Safety rules | ||
| Quality standard | ISO9001 | |
| Environmental standards | All components and packaging materials in compliance with international environmental standards | |
| Technical parameters | ||
| OSD menu language | Multi–language | |
| Horizontal refresh rate | 20 ~ 82KHz (Analog & Digital) | |
| Vertical refresh rate: | 55~75Hz | |
| Compatible video | 480i;480p;576i;576p;720p(50 and 60HZ);1080i(50 and 60HZ);1080p(50 and 60HZ) | |
| Wall hole | 580*300mm | |
| Casing | Metal | |
| Color | Black | |
| Size | 1023.68*578.27*127.4mm | |
| Feature | Intelligent cooling system | Environmental protection mute cooling fan, Energy saving, Reduce the noise, Reduce the temperature, Improve products reliability |
| Low energy consumption backlight system | Energy saving, reduce LCD panel heat, Improve the reliability of LCD monitor, Effectively solve eye fatigue, Convenient for long-term monitoring. | |
| System control way | Chinese/English switching, contrast ration, brightness, definition, color saturation, tone, Signal switching, Source view, Color temperature adjustment, Operation state display. | |
