Help CenterXZS350 High-efficient Powder Sifter
Related Products
XZS500 High-efficient powder sifter
Main Applications :
Our XZS350 High-efficient powder sifter is suited to continuous working mode production, are the ideal equipment for continuous discharging of material of different size ratio after going through sieves.
Principle of structure:
The machine consists of hopper,vibration chamber and couplingand motor. There are eccentric wheel, rubber of parts, main shaftbearing and sp on. The adjustable eccentric weight can drive to the central line of main shaft through motor under the unstable state,it produces centrifugal force that makes raw material from vortex in the sieve. The size of amplitude of eccentric weight can be regulated in accordance with the different raw materials.
The machine is compact in structure ,small in size, free ofdust and makes little noise.It is highly efficient and low energy consuming, easy of moving and easy of maintenance.
Features & Advantages:
1.High efficiency, elegant design & durable, available for any powder and viscous liquid.
2.Easy to operate, easy to change the screen cloth, easy to clean.
3.The screen will never be blocked and the powder will never be soared. Screen clothes under 400 MESH are available.
5.Auto-Discharge facility for impurity and rough material,suitable for integrated operation.
6.Small dimension, save space and easy moving.
7.No mechanical actions, easy aintenance, can be used as the way either single layer or rnulti-layer.
8.Unique & durable design of screen construction, only takes 3-5 minutes for changing the screen cloth.
9.All products contactparts are made of sus 27 (#304).
10.Maximum five layers of screen decks are available.
Main Technical Specifications:
| Modle | XZS350 |
XZS515 |
XZS650 |
| Productivity kg/h | 60-500 |
60-1350 |
180-2000 |
| Screen Meches | 12-200 |
12-200 |
12-200 |
| Screen Diameter mm | φ350 |
φ515 |
φ650 |
| Power kw | 0.55 |
0.75 |
1.5 |
| rpm | 1380 |
1450 |
1370 |
| Overall Dimensions mm | φ540×1060 |
φ710×1290 |
φ880×1350 |
| Net weight kg | 100 |
180 |
250 |
Each model is provided with double,or triple outlets | |||
Adjustment of vibratiy rang 1-6 mm | |||
About us:
Nuoya Machinery Company is one famous group and apply itself to R&D and manufacture machinery for Pharmaceutical, Chemical, food and so etc fields.
The Main products are: Tablet press, Mixer, Crusher, Granulator, Dryer, Coater, Packing machine….we also can make punch die sets and spare parts in standard or not standard.
Our production, examination and supervision are strictly following the ISO9001 international quality system. Owing to high quality, beautiful appearance, warm service and reasonable price, Nuoya products have earned high confidence and reputation in the International market. Currently, Products have sold to America, Australia, Canada, Germany, New Zealand, Russia, dozens of countries and regions.
Contact :
Looking forward to working with you!
Contact: Mr.David Shi
Shenzhen Nuoya Pharmaceutical Equipment Co., Ltd.
TEL: 0086-514-87667998,87667808 FAX: 0086-514-87665265
ADD:No.B of ChuangXin Industry Area,XinTian Guanlan.Baoan District Shenzhen Guangdong China.
