DP30 Vertical Tablet Press
Applications:
Our DP30 Vertical Tablet Press is widely used for pharmacy, chemical, food, and metallurgy industry. It can press round or irregular tablets from various granular materials.It features high precision of filling, low-noise, and low-consumption of material, and it works smoothly. The minimum consumption of lab material is just 200g. It is a good machine for research and development in lab at hospital and plant, used to small-scale production.
Main characteristics:
Design of GMP
Output is adjusted by frequency converter
High precision of filling
Operating reliably and low noise
Lower consumption of material
Main technical specifications:
Item |
DP30 |
Punch stations (set) |
1 |
Max. tablet diameter (mm) |
20 |
Max. main operation pressure (kN) |
30 |
Max depth of fill (mm) |
20 |
Max tablet output (tablets/min) |
60 |
Power of main motor (kW) |
0.55 |
Power |
AC 220V, 50Hz/AC 110V, 60Hz |
Overall dimensions (mm) |
708 x 459 x 740 |
Weight (kg) |
150 |
