Specifications
THP-10 Candy Tablet Press1.Automatic CE/GMP single punch candy tablet press
2.Stainless steel candy tablet press machine
THP-10 Candy Tablet Press
Applications:
Our THP-10 Candy Tablet Press is the single punch tablet press machine, it is the small continuous automatic tablet press which is one of the essential equipments for pressing granular raw materials into bablets or medicines taken with water in pharmaceutical, chemical, food, electronics industries.
It can be used to press medicinal tablets, catalysts, candies, caloium coffee pills, powder metallurgical parts electronics components, varoius tablets of pesticide and fertillizer etc. in small-batch production, laboratory and hospital. The machine can press special-shaped, ringlike tablets of different kinds, and can also process the tablets of pesticide both sides are impressed trademarks, letters and simple pattems.
Main Technical Data:
ITEM |
THP-10 |
Max.Pressure (KN) |
100 |
Max.Dia of Tablet (mm) |
40 |
Max.Depth of Fill (mm) |
45 |
Max.O.D.of Ringlike Tablet (mm) |
35 |
Hole Dia of Ringlike Tablet (mm) |
6-14 |
filling Depth of Ringlike Tablet (mm) |
45 |
Production Capacity (pc/min) |
34-50 |
Motor (KW) |
3.7 |
Overall Size (L*W*H) (mm) |
666*860*1824 |
Net Weight (kg) |
750 |
