Help CenterGS Series Lab Auger Conveyor
Related Products
Specifications
GS Series Auger conveyor1.Double electromotors Auger conveyor.
2.Powder product GMP/CE Auger conveyor.
3.Stainless conveyor.
GS Series Lab Auger conveyor
Brief instruction:
Our machine, GS Series Lab Auger conveyor is suitable for multiple powdery product , working together with kinds of packing machine, the product feeding of the conveyor is controlled to retain the product level in the product cabinet . And the machine can be used independently . All parts are make of stainless steel except the electromotor , bearing and support frame .
Characteristic:
1.Using double electromotors: feeding motor & vibrating motor , separately controlled .
2.Product funnel is design to be adjustably vibratile , which lead to avoid product blocking and improve the adaptation of different products.
3. Product funnel can separate from the tube for easy assembly.
4. Special anti-dust design to protect bearing from dust.
5. In order to convenience machine cleaning , following functions are added in : auger can reverse for emptying the tube, product discharge gate is mounted in the bottom of the funnel , auger can be disassemblied for washing.
Specification :
Model |
GS-A1 |
GS-A2 |
Capacity |
3m3 /h |
5m3 /h |
Cabinet Cubage |
230L |
230L |
Conveyor Height |
1.8m (other height optional) |
1.8m (other height optional) |
Motor Power |
930W |
1700W |
Power |
380V / 50-60Hz |
380V / 50-60Hz |
Weight |
130kg |
160kg |
Cabinet Dimension |
860 * 900* 1100 mm |
860 * 900* 1100 mm |
Service:
A. To pick up machine more easy & correct.
First, We need client to provide below information about their product:
1) The requirement of raw material: we require powder or grains with good fluidity & dry, can fall down from cone charging barrel.
2) We need know the size, shape of tablets / pills. Yield(capacity) in your request.
So we can figure out if our machine can compress and which models will meeting with your requirement.
B. We can design, customize and make dies for customers.
