LTE 4G Signal Booster Repeater Amplifier Indoor

LTE 4G Signal Booster Repeater Amplifier Indoor


It's time for a lte 4g signal booster repeater amplifier indoor !

Lte 4g signal booster repeater amplifier indoor are very effective equipment that can offset the covering shortage of the base station of the mobile network, expand the cover range of the base station and fill the signal blind zone to ensure the convenient and pleasant communication. The only requirement signal repeater need for all this is at least middle range signal outside this area.

If you are in such a situation and thinking about your own repeater, please bare in mind that all our products have a huge list of advantages:
1) In our casemore bars more calls. Signal booster provides the well-organized service that's why after installation of the system the quality of the connection will be really great.
2) Signal Repeater requireno additional wiresbeing attached to your cell phone thus allowing you to use your cell phone without any extra troublesome accessories,in otherworlds, no physical connection to your cell phone.
3) They arepractical, beautiful, easy to installand with competitive price. You will not need to hire anybody to provide the installation of the equipment. You'll be able to install it by yourself using only the manual list attached to your signal repeater.
4) Signal booster works atfull duplex. It means that they are not only receiving the signal from the base mobile station but they also send the signal to the base mobile station.
5) Our equipment iscompletely safe. Signal booster don't produce any radiation
6) Signal boosters are able tocover different coverage: from small to large. In this case you can decide which of signal repeater is suitable for your office or supermarket.


Introduction To Mobile Phone Signal Repeater
1. Enhance Mobile Phone Signal Strength
2. Improve Communication Quality
3. Reduce Cellphone Radiation
4. Protract Cellular Battery Life
5. Economic Building Cost
6. Easy Operation
7. Easy Installation
8. Build-in Power Supply

Features
High gain, easy installation and operation.
Full-duplex, single-port design, build-in power supply.
Use ALC technology,  adjust extent automatically
LED Light Working & Signal Condition Indicators
Big linear power,  control intermodulation & scatteration stably
Dependability stand by GB6993-86 standard
Compatibility of electromagnetism according with ETS300 609-4
CE and RoHs Approved


Technique:
Frequency range
Uplink 2500~2570MHz
Downlink  2620~2690MHz
Gain ( dB)
Uplink  Gp≥60 Downlink   Gp≥65
Export power (Po)
≥20dBm
Pass band ripple
≤3dB
I/O impedance
50Ω/N connector
Noise figure
≤4dB
Transmission Delay
≤0.5μs
Ambient temperature
-10°C~60°C
Power supply
AC110V~220V to DC+5V/2A
Size
  159(W)*101(D)*29.6(H)
Reliability
To the GB6993-86 standard
Electromagnetic
 compatibility
To the ETS300 694-4 standard
Function
a) Power supply LED denote
b) Export power LED denote
coverage  area
1000-1500m2





Installation Approaches:

1) Fix up outdoor antenna reception on housetop or outside the window and point it to the signal tower.

2) Connect outdoor antenna to “BTS” port in repeater machine through cable.

3) Connect indoor antenna(s) to “MOBILE’ port in repeater machine through cable also.

4) Plug power adaptor into AC power socket and finish installation.
