Huawei E5186s-22 LTE FDD 800/900/1800/2100/2600Mhz TDD2600Mhz Cat6 300Mbps Mobile Gateway Router

Huawei E5186s-22 LTE FDD 800/900/1800/2100/2600Mhz TDD2600Mhz Cat6 300Mbps Mobile Gateway Router thumbnail-1
Huawei E5186s-22 LTE FDD 800/900/1800/2100/2600Mhz TDD2600Mhz Cat6 300Mbps Mobile Gateway Router photo-1
US$ 340 - 355 MOQ: 1 Piece
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Wireless
Application:
Soho
Contact Supplier Request Quote Chat Now
Shenzhen Chu-Tech Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Type Wireless
Application Soho
Function Firewall, QoS, VPN
Certification CE
Brand Name Huawei
Model Number E5186s-22
Place of Origin China



Huawei E5186s-22 LTE FDD 800/900/1800/2100/2600Mhz TDD2600Mhz Cat6 300Mbps Mobile Gateway Router

Product Description



Huawei E5186 4G LTE Router Technische Daten:

* LTE CAT6 Download-Geschwindigkeit bis zu 300Mbps, Upload-Geschwindigkeit zu 50 Mbps @ 20MHz 20MHz + BW

* Huawei E5186s-22a: LTE FDD DD800/900/1800/2100/2600MHz, TDD-2600MHz

* Huawei E5186s-61a: LTE FDD 700/1800/2600MHz  TDD 2300MHz

* DC-PA + / HSPA + / UMTS 900/2100MHz

* GSM / GPRS / EDGE 850/900/1800/1900 MHz

* WiFi 802.11b/g/n/ac, 2.4GHz/5GHz, bis zu 64 Geräte

* 4 RJ45 (GE)-Schnittstelle RJ11 Schnittstelle + 2 + 1 USB-Host-Schnittstelle

* Firewall, CS Stimme, VoIP, VoLTE, TR069 Remote Management

* HTTP-Online-Upgrade, QoS, USB-Freigabe, UPnP

* IPV6, DLNA, Fax, Print, VPN



Features and characteristics of Huawei E5186


Manufacturer and type designation   Huawei E5186s-22 (HiSilicon chip)
Download rate   Up to 300 Mbit/s
Upload rate   Up to 50 Mbits/s
Supported LTE Bands:   LTE 2600 MHz / 2100 MHz / 1800 MHz /
900 MHz / 800 MHz (FDD) + LTE 2600 MHz TDD
LTE-Advanced Support   yes (first time)
Backward compatible with   HSPA/HSPA+/UMTS (900/2100 MHz); GSM
MIMO Support   MIMO 2×2
Connector for external antenna   yes, 2 SMA connectors (Buy Huawei E5186 Antenna)
Category   LTE modem category 6! (CAT6)
Telephone
With integrated telephone system   yes, VOIP SIP Client
Support VoLTE (Voice over LTE)   yes
Connection for analog phones   yes, 2xRJ11
DECT   no
Integrator answering machine   -
Network | LAN & WLAN
LAN ports   4 LAN Gigabit ports (RJ45)
WLAN standards   WLAN 802.11b/g/n/ac for up to 64 users
5 GHz WLAN support   yes
Encoding   WEP, WPA, WPA2
USB   yes, 1 x USB 2.0
Dimensions / Weight   194 x 177 x 64 mm and 450 grams

 Huawei E5186s-22 LTE FDD 800/900/1800/2100/2600Mhz TDD2600Mhz Cat6 300Mbps Mobile Gateway RouterHuawei E5186s-22 LTE FDD 800/900/1800/2100/2600Mhz TDD2600Mhz Cat6 300Mbps Mobile Gateway RouterHuawei E5186s-22 LTE FDD 800/900/1800/2100/2600Mhz TDD2600Mhz Cat6 300Mbps Mobile Gateway RouterHuawei E5186s-22 LTE FDD 800/900/1800/2100/2600Mhz TDD2600Mhz Cat6 300Mbps Mobile Gateway RouterHuawei E5186s-22 LTE FDD 800/900/1800/2100/2600Mhz TDD2600Mhz Cat6 300Mbps Mobile Gateway Router
