Home > Products > Powder Mixer > Double Ribbon Mixer for powder
Double Ribbon Mixer for powder
- 100 Set / Sets per Month
- Shanghai
- Credit Card
You May Like
Product Details
| Condition | New | Mixer Type | Ribbon | |
| Product Type | Paint | Application | Powder | |
| Additional Capabilities | Other, Mixing | Place of Origin | Shanghai, China | |
| Brand Name | ELE | Model Number | EWJ | |
| Max. Loading Capacity | 5000L | Voltage | 380V | |
| Power(W) | 0.75KW~45KW | Dimension(L*W*H) | as model | |
| Certification | ISO,CE | Warranty | 12 Months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Ribbon Powder Mixer
Application
The horizontal ribbon mixer is widely used in industrial production like Powder, viscosity material or cohesive powders,or mushy materials or powders add liquid materials. Coating, Dry Mortar, Amuscular, and Thermal Insulation Materials, etc.
Composition
It consists of U-vessel, ribbon blade, transmission parts.
Working Principle
The ribbon blade is usually double layers or three layers,the outer spiral ribbon concentrates the materials from the side to the centre while the inner spiral ribbon transports the matetials from centre to side, shape the convective mixing.
Features
Spiral ribbon mixer can provide favorable performance to the mixing of viscosity substances, or powder particles in coherency property, and the mixing of liquid or pasty substances into powder particles. The cover can be full open or enplas, it is easy to clean or maintenance machine.
Discharge
Bottome discharge, completely discharge.
Technical Parameters
Model | Capacity (L) | Power (kw) | Length (mm) | Width (mm) | Height (mm) | Weight (kg) |
EWJ-5 | 5 | 0.2 | 1080 | 610 | 720 | 280 |
EWJ-500 | 500 | 4 | 2450 | 1150 | 900 | 1100 |
EWJ-1000 | 1000 | 7.5 | 3100 | 1800 | 1200 | 2300 |
EWJ-2500 | 2500 | 11 | 3980 | 2280 | 2150 | 3380 |
EWJ-4000 | 4000 | 22 | 4290 | 2390 | 2240 | 4370 |
EWJ-5500 | 5500 | 30 | 4970 | 2960 | 2330 | 8100 |
EWJ-8500 | 85000 | 37 | 5700 | 3600 | 2900 | 12300 |
EWJ-12000 | 12000 | 45 | 6100 | 4200 | 3600 | 18300 |
EWJ-20000 | 20000 | 55 | 6652 | 4600 | 3930 | 23700 |
Other Kinds of Powder Mixers
