Horizontal Ribbon Mixer
- Shanghai
You May Like
Product Details
| Mixer Type | Ribbon | Application | Viscous Fluid | |
| Additional Capabilities | Other, Dispersion | Place of Origin | Shanghai, China | |
| Brand Name | ELE | Model Number | EBF-R |
Product Description
Specifications
1.Horizontal Mixer2.good effect to viscosity material
3.easy to clean and maintenance
4.discharge completely
Horizontal Ribbon Mixer
Introduction
The horizontal ribbon mixer is widely used in industrial production like Powder Coating, Dry Mortar, Amuscular, and Thermal Insulation Materials, etc.
Composition
It consists of U-vessel, ribbon blade, transmission parts.
Working principle
the ribbon blade is usually double layers or three layers,the outer spiral ribbon concentrates the materials from the side to the centre while the inner spiral ribbon transports the matetials from centre to side, shape the convective mixing.
Features:
Spiral ribbon mixer can provide favorable performance to the mixing of viscosity substances, or powder particles in coherency property, and the mixing of liquid or pasty substances into powder particles.
The cover can be full open or enplas, it is easy to clean or maintenance machine.
Discharge
Bottome discharge, completely discharge.
Parameters:
Model | Capacity/L | Main Power/kw | Length/mm | Width/mm | Height/mm | Weight/kg |
EWJ-5 | 5 | 0.2 | 1080 | 610 | 720 | 280 |
EWJ-500 | 500 | 4 | 2450 | 1150 | 900 | 1100 |
EWJ-1000 | 1000 | 7.5 | 3100 | 1800 | 1200 | 2300 |
EWJ-2500 | 2500 | 11 | 3980 | 2280 | 2150 | 3380 |
EWJ-4000 | 4000 | 22 | 4290 | 2390 | 2240 | 4370 |
EWJ-5500 | 5500 | 30 | 4970 | 2960 | 2330 | 8100 |
EWJ-8500 | 85000 | 37 | 5700 | 3600 | 2900 | 12300 |
EWJ-12000 | 12000 | 45 | 6100 | 4200 | 3600 | 18300 |
EWJ-20000 | 20000 | 55 | 6652 | 4600 | 3930 | 23700 |
Spiral Ribbon
