Help CenterPaint Mixing Series High Speed Disperser
Related Products
-
EC,EG,SC,AC,OL Pesticide High Speed DissolverUS$ 800 - 50,000MOQ: 1 Set -
Hydraulic Lifting Printing Ink & Paint Mixing MachineUS$ 800 - 50,000MOQ: 1 Set
-
Printing Ink & Paint High Speed DissolverUS$ 800 - 50,000MOQ: 1 Set
-
Printing Ink & Paint Explosion Proof High Speed DissolverUS$ 800 - 50,000MOQ: 1 Set
-
ELE Industrial Paint Mixing MachineUS$ 700 - 40,000MOQ: 1 Set
Mixing Equipment/ Mixing Machine
Description
High speed disperser suitable for batch production, it is apply to all kind of liquid to pre-mix, disperse,
color matching, etc.
Features
Hydraulic lifting, the frame can turn around flexible,
- With inverter, various speed control, low noise and long-time continuous production,
- Stable performance, high efficiency,
- According to requirement, can with clamp or belt,
- Motor: Siemens , with explosion-proof and no ex-proof,
- One machine can serve several tanks,
Specifications
Model |
Power(kw) |
Speed(rpm) |
Diameter of Disc(mm) |
Stroke(mm) |
Pump Power(kw) |
Weight (kgs) |
EBF-4 |
4 |
1440 |
100-200 |
700 |
0.75 |
700 |
EBF-7.5 |
7.5 |
1440 |
200-300 |
900 |
1.1 |
1000 |
EBF-11 |
11 |
1440 |
200-300 |
900 |
1.1 |
1000 |
EBF-15 |
15 |
1440 |
200-300 |
900 |
1.1 |
1000 |
EBF-18.5 |
18.5 |
1250 |
300-400 |
1200 |
2.2 |
1500 |
EBF-22 |
22 |
1250 |
300-400 |
1200 |
2.2 |
1500 |
EBF-37 |
37 |
1250 |
300-400 |
1200 |
2.2 |
1800 |
EBF-45 |
45 |
1250 |
400-500 |
1500 |
2.2 |
1800 |
EBF-55 |
55 |
1250 |
400-500 |
1500 |
2.2 |
2000 |
Remarks
1.If solvent-based product, the motor can be explosion-proof, with on-spot expolsion-proof control box.
2. The machine can be customized according to practicle condition and specific requirment.
